1.

PRODUCT OVERVIEW

The B-660-EXT-444-100AS is a 4K HDR HDBaseT extender with HDMI loop out and support
for 4K@60Hz 4:4:4 8bit including DCI 4K (4096 x 2160), and HDCP 2.2 compatibility. It can
transmit 1080P signals up to 100m/330ft and 4K@60Hz signals up to 70m/230ft via Cat 5e/6
cable, and transmit 1080P and 4K@60Hz 4:4:4 8bit signals up to 100m/330ft via Cat 6a/7
cable.
The B-660-EXT-444-100AS supports bi-directional IR pass through, RS-232 pass through,
CEC pass through, S/PDIF pass through and ethernet pass-through. It also supports ARC
function, which can be configured by the Function DIP switch. With bi-directional PoC support,
only one power adapter is needed. The built-in scaler, is capable of scaling down the incoming
4k (including 3840x2160 and 4096x2160) video signal automatically to 1080P when the
connected display is not able to reproduce the 4k signal.
Two independent 4-pin Video and Audio EDID DIP Switches provide a variety of EDID
combinations to fit the needs of the installation and operation environment. The 6-pin Function
DIP Switches provide a variety of configurations and upgrading requirements to fit multiple
application scenarios.
2.

FEATURES

• Supports resolutions up to 4K@60Hz 4:4:4 8bit and HDCP 2.2.
• Supports HDR (High Dynamic Range), including HDR 10, HLG up to 4K@60 and HDR 10+
and Dolby Vision up to 4K@30Hz.
• The transmitter supports local output/loop out.
• Supports digital and analog audio de-embedding and S/PDIF pass through.
• Over a Cat 5e/6 cable, HDBT transmits 4K@60Hz 4:4:4 8bit up to 70m/230ft, and 1080P up
to 100m/330ft; Over a Cat 6a/7 cable, HDBT transmits 4K@60Hz 4:4:4 8bit and 1080P up
to 100m/330ft.
• DIP Switches configure EDID, IR, RS-232, ARC functions and FW update.
• Ability to down-scale automatically.
• CEC pass through capable.
• Supports bi-directional IR pass through, RS-232 pass through and ethernet pass through.
• Bi-directional PoC, one power adapter at either transmitter or receiver side can power both
units.
3.

PACKAGE CONTENTS

• 1 x B-660-EXT-444-100AS Extender
• 1 x DC 12V Power Adapter with US Pins
• 4 x Mounting Ears (with Screws)
• 4 x Drywall Screws
• 8 x Rubber Feet
• 1 x Installation Manual
