Product overview

The product is an extender for HDMI eARC and SPDIF audio pass-through. It supports CEC

pass-through between HDMI ARC input port and ARC output port to handshake for eARC transmission.

For TVs that don't support HDMI eARC capabilities, the extender provides an independent SPDIF audio

pass-through channel. SPDIF audio can be transmitted from the SPDIF IN port of the transmitter to the

SPDIFOUT port of the receiver.

Features

• Supports CEC pass-through between HDMI ARC Input port and ARC Output port to handshake for

ARC transmission.

• Supports signal transmission distance up to 70m/230ft via a single Cat Se or above cable.

• Supported returned audio formats include: Dolby Digital+ (DD+) , Dolby 5.1CH, DTS 5.1CH and

LPCM 2CH.

Pro tip:

To set the extender to eARC or SPDIF mode, users need to set the DIP switches of the

transmitter and receiver to the same position. For example, when the extender is set to

eARC mode, the DIP switches of transmitter and receiver both need to be switched to the

"ARC" position.

• 1X B-260-ARC Transmitter

• 1X B-260-ARC Receiver

• 2 X DC 5V Power Adapter

• 4x Mounting Ears (with Screws)

• 4x Mounting Screws

• 8 X Rubber Feet

• lx User Manual
