OWNER'S MANUAL
B-200-1CAT-HDIR
WELCOME TO THE BINARY™ BRAND OF PRODUCTS
This product is engineered to provide years of exceptional reliability. Binary™
is one of the most highly regarded brands available today. We appreciate your
business and we stand committed to providing our customers with the highest
degree of quality and service in the industry.
Binary™ Single Cat 5e/6 HDMI 1.4
>>
3DExtender Plus IR Receiver & Flasher
Pass-Through (130 Ft.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B-200-1CAT-HDIR and is the answer not in the manual?

Questions and answers

Related Manuals for Binary B-200-1CAT-HDIR

Summary of Contents for Binary B-200-1CAT-HDIR

  • Page 1 B-200-1CAT-HDIR WELCOME TO THE BINARY™ BRAND OF PRODUCTS This product is engineered to provide years of exceptional reliability. Binary™ is one of the most highly regarded brands available today. We appreciate your business and we stand committed to providing our customers with the highest...

  • Page 2: Important Safety Instructions

    CAUTION: To reduce the risk of electrical shock, inspect the premises carefully. Do not use the unit if proper equipment grounding cannot be verified. PACKAGE CONTENTS • (1) B-200-1CAT-HDIR (Transmitter and Receiver) • (4) Mounting Screws • (8) Rubber Feet •...
  • Page 3 INTRODUCTION The B-200-1CAT-HDIR extends HDMI over single Cat5e/6 allowing video and audio transmission. In addition, the B-200-1CAT-HDIR is equipped with bi-directional IR pass-through allowing users to boost IR control distance up to 200 ft. making IR control possible with no additional wires. The B-200-1CAT-HDIR also supports the most advanced 3D video format, which is compliant with HDMI 1.4 3D...

  • Page 4: Input Panel

    INPUT PANEL OUTPUT PANEL TRANSMITTER NOTE: Transmission distance up to 200 feet at 1080i, 130 feet at 1080p (24-Bit), and 65 feet at 1080p (36-Bit) 1. MODE: EDID Setting Supported Resolutions Color Depth Audio Channels 1080p @60 24-Bit 1080p @60 24-Bit 1080p @60 36-Bit...

  • Page 5: Edid Learning

    4. The LED on the RJ45 of the transmitter will flash On and Off once to learn the EDID. Keep the mode dial on “7” at all times to use the learned EDID. 5. Unplug the HDMI cable from the display and follow the installation instructions below to install the B-200-1CAT-HDIR.

  • Page 6: Ir Pass-Through

    NOTE: This product was specifically engineered for Episode ® IR products. Use of the following products is highly recommended (items not included). IR Flasher Mini Mono Cable IR Receiver (Episode ® IRF-1 Binary™ B3-MonoMini-.5, ® (Episode IR-SM-3660 or Episode ® IRF-2) B3-MonoMini-1, or B3-MonoMini-2 ® or Episode...

  • Page 7: Installation

    Test the connections. SIGNAL IN IR OUT IR RECEIVER (Episode® IR-SM-3660 or Episode® IR-TT-3660) Cat5e/6 Cable MINI MONO CABLE Binary™ B3-MonoMini-.5, B3-MonoMini-1, or B3-MonoMini-2 RECEIVER TRANSMITTER IR FLASHER (Episode® IRF-1 or Episode® IRF-2) INSTALLATION 1. Learn the EDID from the Display to the Transmitter (see EDID Learning section) or select the appropriate mode (see transmitter section).

  • Page 8: Warranty

    2-Year Limited Warranty This Binary™ Product has a Two-Year Limited Warranty. This warranty includes parts and labor repairs on all components found to be defective in material or workmanship under normal conditions of use. This warranty shall not apply to products which have been abused, modified or disassembled.
