Specifications - Binary B-660-EXT-444-100A Installation Manual

9.

SPECIFICATIONS

Technical
Input/Output Port
Input/Output Signal Type
Input/Output Resolution Supported
Audio Format
Maximum Data Rate
Control Method
General
Operating Temperature
Storage Temperature
Humidity
ESD Protection
Power Supply
Power Consumption (Max)
Device Dimension
(W x H x D)
Product Weight
Transmitter:
1 x HDMI IN, 1 x HDBT OUT, 1 x HDMI OUT,
1 x IR Receiver,1 x IR Flasher,
1 x RS-232 (RJ45),
1 x AUDIO OUT (3.5mm analog audio out),
1 x SPDIF OUT, 2 x ETHERNET, 1 x DC 12V IN
Receiver:
1 x HDMI OUT, 1 x HDBT IN, 1 x IR Receiver,
1 x IR Flasher, 1 x RS-232 (RJ45),
1 x AUDIO OUT, 1 x SPDIF IN,
2 x ETHERNET, 1 x DC 12V IN
HDMI with 4K@60Hz YUV 4:4:4, HDCP 2.2,
including DCI 4K (4090x2160)
VESA:
800x600 , 1024x768
8
1280x800 , 1280x960
8
1360x768 , 1366x768
8
1600x900 , 1600x1200
8
1920x1200 , 2560x1440
8
SMPTE:
1280x720P , 1080I
6,7,8
1920x1080P
1,2,3,4,5,6,7,8
3840x2160P
2,3,5,6,8
NOTE: = at 23.98 Hz,
1
Hz, = at 29.97 Hz,
4
at 59.94 Hz, = 60 Hz,
8
HDMI IN/OUT: Fully supports audio formats
in HDMI 2.0 specification, including PCM
2.0/5.1/7.1, Dolby TrueHD™, Dolby Atmos™,
DTS-HD Master Audio™ and DTS:X™
3.5mm Analog AUDIO OUT: PCM 2.0
SPDIF: PCM 2.0, Dolby Digital™, DTS 5.1™
HDMI IN & HDMI OUT: 18Gbps
IR, RS-232, CEC, DIP Switches
0°C to 40°C (32°F to 104°F)
-20°C to 60°C (-4°F to 140°F)
10% to 90%, non-condensing
Human-body Model:
±15kV (Air-gap discharge)
DC 12V 3A
Receiver is powered by transmitter: 24.05W
Transmitter is powered by receiver: 23.67W
Transmitter and receiver are powered
separately: Transmitter: 8.95W,
Receiver: 11.05W
194mm x 15.4mm x 110mm/7.64" x 0.61"
x 4.33" (Transmitter/Receiver, without
mounting ears)
0.42kg/0.93lb
17
, 1280x768 ,
8 8
, 1280x1024 ,
8 8
, 1440x900 ,
8 8
, 1680x1050 ,
8 8
, 2560x1600
8
,
6,7,8
,
, 4096x2160P
2,3,5,6,8
= at 24 Hz, = at 25
2 3
= at 30 Hz, = at 50 Hz,
5 6
= 75 Hz
9
8
=
7
