EDID MANAGEMENT

EDID is configured by Video and Audio DIP Switch. The default setting is Auto, please refer to
the following table to configure.
Video
EDID Resolution
0 Auto (Default)
1 1080P SDR
2 1080P HDR
3 4K@30 SDR
4 4K@30 HDR
5 4K@60 4:2:0 SDR
6 4K@60 HDR
Audio
EDID Resolution
0 Auto (Default)
1 2CH (PCM)
2 6CH (PCM)
3 Compressed 5.1
4 8CH (PCM)
5 Compressed 7.1
O
1 2 3 4
N
1
Up
Up
Up
Up
Up
Up
Up
1
Up
Up
Up
Up
Up
Up
12
DIP Switch Position
2 3
Up Up
Up Up
Up Down
Up Down
Down Up
Down Up
Down Down
DIP Switch Position
2 3
Up Up
Up Up
Up Down
Up Down
Down Up
Down Up
4
Up
Down
Up
Down
Up
Down
Down
4
Up
Down
Up
Down
Up
Down
