IR PASS-THROUGH

IR signals can be passed from the transmitter to the receiver over the
Cat5e/6 cable. Each unit will need both an IR Receiver and an IR Flasher
(sold separately). This allows the units to receive IR information and transmit it.
CAUTION: Incorrect connection of the IR Flasher and Receiver may result in
IR extender failure. Check carefully before plugging in the IR extender to the
respective IR sockets. Warranty will not cover the damage.
NOTE: This product was specifically engineered for Episode
Use of the following products is highly recommended (items not included).
IR Flasher
(Episode
or Episode

SPECIFICATIONS

IR Signal (Tip) Grounding
(20-60 kHz)
IR ADAPTER CABLE FOR CONTROL SYSTEMS (INCLUDED)
IR Signal (Tip)
(20-60 kHz)
® IRF-1
® IRF-2)
IR FLASHER
(Ring)
Grounding 12V DC
(Ring) (Sleeve)
IR Receiver
®
(Episode IR-SM-3660
®
or Episode IR-TT-3660)
IR RECEIVER
® IR products.
Mini Mono Cable
Binary™ B3-MonoMini-.5,
B3-MonoMini-1, or B3-MonoMini-2
12V DC
Grounding
(Sleeve)
(Ring)
IR Signal (Tip)
Grounding
(Sleeve)
IR Signal (Tip)
(20-60 kHz)
