Page 1 AT&T 555-530-710 Issue 1, June 1988 AT&T SYSTEM 25 TERMINAL OPERATIONS MANUAL...
Page 2 However, this information is subject to change. This document will be reissued periodically to incorporate changes. Terminal Operations Manual for R2V1 Prepared by System 25 Document Development Group and the Technical Publications Group...
Page 3: Table Of Contents
Contents Introduction Introduction System 25 Voice Terminal Overview Voice Terminal Features 2 - 1 Account Code Entry 2 - 5 Automatic Intercom Bridged Access 2 - 7 Call Accountability 2 - 9 Callback Request (Callback Queuing) 2 - 1 1...
Page 4 Voice Terminal Features (Continued) Signaling (Manual Signaling) 2-91 2-93 Speaker Speakerphone 2-95 2-97 Speed Dialing 2-99 Station Message Waiting Testing a Voice Terminal 2-101 2-103 Transfer Attendant Features 3 - 1 Answering Calls Attendant Message Waiting 3 - 3 Automatic Release and Automatic Hold 3 - 5 Call Waiting 3 - 7...
Page 5: Introduction
Technicians. It provides the same instructions for using System 25 voice and data terminals as found in the Data Features User Guide and in the user guides for System 25 voice terminals. It also includes information from the System 25 R2V1 Reference Manual.
Page 6 1-2 Introduction...
Page 7: System 25 Voice Terminal Overview
System 25 Voice Terminal Overview This section is an overview of System 25 voice terminal operation. It describes the functions of voice terminal tones, lights, and feature buttons. Voice Terminals Supported System 25 supports a maximum of 142 multiline voice terminals in addition to two multilines assigned as attendant consoles.
Page 8 Assignable features are assigned by the System Administrator. Feature Access Codes Some System 25 features require the user to dial a code to access the feature. These codes are specified in the operating instructions reference that follows. For convenient reference, they are summarized below.
Page 9 Third-Party Call Setup (a data feature). Handset Tones System 25 signals users with tones that are heard through the handset. The tones and their descriptions are listed below. (a continuous steady tone) DIAL TONE The user can dial.
Page 10 Single-Line Voice Terminals The Switchhook (Recall) The switchhook is used in single-line voice terminal procedures. The switchhook is the button(s) pressed down by the handset when not in use. When the user is instructed to press the switchhook, the switchhook must be pressed down firmly as far as it will go for approximately 1/2 second and then released.
Page 11 I-use LED and a green status LED should be used for the SA function. If not, call appearance conditions cannot be easily monitored. The System 25 R2V1 Implementation Manual and the System 25 R2V1 Administration Manual provide additional information about button labeling and options.
Page 12 NOTE: conversation on hold, the first call will be dropped. Attendant Consoles Two types of attendant consoles are available with System 25: Direct Trunk Attendant Consoles (DTACs) Switched Loop Attendant Consoles (SLACs) A SLAC or DTAC can be used with or without a Direct Extension Selector Console. The setup used will depend on the size and needs of the company.
Page 13 The number of calls waiting in the SLAC queue is shown on the right side of the Screen 1 display. If between 1 and 9 calls are waiting for service, the actual number appears. A queue of ten or more calls is indicated by “ !”. System 25 Voice Terminal Overview...
Page 14: Account Code Entry
Automatic Route Selection (ARS) calls to 911 or designated emergency numbers System 25 can be administered to accept account codes of one to fifteen digits. After the correct number of account code digits has been entered (or # is entered to signal end-of- dialing), confirmation tone is followed by dial tone.
Page 15 Multiline Entering Account Codes for Outgoing Calls Lift the handset and listen for dial tone. Dial. Dial the account code or speed dialing code, or press the button [REP DIAL] associated with the account code. If you make a mistake while entering the account code, NOTE: again and then the account code.
Page 16 Single-Line Entering Account Codes for Outgoing Calls Lift the handset and listen for dial tone. Dial. Dial the account code or speed dialing code that is associated with the account code. If you make a mistake while entering the account code, NOTE: d i a l again and then the account code.
Page 17 2-4 Voice Terminal Features...
Page 18: Automatic Intercom
Automatic Intercom This feature applies to multiline voice terminals only. The Automatic Intercom feature allows a multiline voice terminal user to place calls to and answer calls from another station by use of a dedicated button appearance. The Automatic Intercom feature is usually set up between two system users who frequently call each other. To use this feature, the AUTO ICOM button is pressed instead of dialing the other person’s PDC.
Page 19 2-6 Voice Terminal Features...
Page 20: Bridged Access
Bridged Access This feature applies to multiline voice terminals only. The Bridging feature allows a multiline voice terminal user to handle calls on a BRIDGED ACCESS (BA) button associated with a SYSTEM ACCESS (SA) button on another multiline station (the principal station). The BA button can be used to cover or join calls in progress on the associated SA button.
Page 21 The table shown below summarizes the effect of different settings for these ring options. BRIDGING STATION PRINCIPAL STATION No Ring Immediate Ring Delayed Ring Administered Administered Administered Administered to send no ring immediate ring delayed ring_ ring on no answer? no ring no ring no ring...
Page 22: Call Accountability
Call Accountability The Call Accountability feature allows system users to charge outside calls made from other users’ stations to their own PDCs. The accountable PDC will be reported in the PDC field of the SMDR record. This feature is not used when calling from one’s own station, or when making inside calls from any station.
Page 23 2-10 Voice Terminal Features...
Page 24: Callback Request (Callback Queuing) 2 - 1
Callback Request (Callback Queuing) The Callback Request (Callback Queuing) feature provides System 25 users with a simple way to complete calls to busy facilities (stations or trunk groups), without having to manually repeat the calling procedures. This feature saves time for users because they can avoid repeated dialing of busy numbers.
Page 25 Callback Queuing Considerations for Inside Calls: If queuing tone is heard, the call has automatically been put into a queue. If busy tone is heard, callback can be requested manually. If special ringback tone is heard, callback can be requested manually. Off-Hook Queuing After a call has been queued, the caller can wait off-hook for the connection to be completed.
Page 26 To make an outside call, the user either dials the Automatic Route Selection (ARS) access code or the pooled facility, then after second dial tone, the rest of the desired outside number. If all trunks in the selected group are busy, and the calling station is administered for automatic queuing for outside calls, queuing tone is returned to the caller.
Page 27 Canceling a Callback Request Lift the handset and listen for dial tone. Press the button associated with the call. Press [DROP] Press the button associated with the call again. Hang up. Single-Line A single-line voice terminal can queue only one call at a time. Requesting Callback Press the switchhook.
Page 28 Call Waiting The Call Waiting feature allows a user at a busy voice terminal to be audibly alerted when another party is calling. A voice terminal is considered busy if all of its SYSTEM ACCESS buttons are in use (multiline sets), if it is off-hook (single-line sets), and if all coverage points are busy.
Page 29 Multiline Answering by Holding Other Calls Press [HOLD] press an idle button. [SYS ACC-O] [BRIDGED ACCESS] Dial Answering by Ending an Existing Call Hang up. When the voice terminal rings, lift the handset. Single-Line Answering by Holding the Existing Call Press the switchhook.
Page 30 A single-line voice terminal can set up a conference between three parties; any of the conferees who are System 25 users may then add other parties to the conference to reach the five-party maximum.
Page 31 Dropping a Conferee When a conferee is dropped, all parties that were added by the dropped conferee are also dropped. In addition, the entire conference may be dropped if a person attempts to drop the individual who added him/her to the conference. Press [DROP] Press the button of the conferee you want to drop.
Page 32: Coverage - Group 2 - 1
The System Administrator determines the number of rings before unanswered calls are sent to coverage. System 25 can have two types of Group Coverage receivers. They can be either standard coverage group receivers, or Direct Group Calling (DGC) coverage group receivers. Both types are reviewed below.
Page 33 Up to 32 coverage groups can be established using coverage group numbers 1 through 32. Each group can have up to eight receivers. There is no limit on the number of senders, but each sender can be covered by only one group. Coverage group senders may also receive individual coverage or be assigned to a pickup group.
Page 34: Coverage - Individual 2 - 2
Coverage— Individual This feature is very similar to Group Coverage, covered in the preceding feature description. The primary difference is that Individual Coverage is a one-on-one type coverage between pairs of stations. There is no limitation on the number of stations that can receive Individual Coverage.
Page 35 2-22 Voice Terminal Features...
Page 36 Direct Group Calling Direct Group Calling (DGC) allows incoming calls to be directed to a specific group of terminals. Calls to a DGC group hunt in a circular manner, starting at the terminal following the last one to receive ringing (whether answered or not), and will ring at the next idle terminal in the group.
Page 37 Leaving the Group Temporarily Lift the handset and listen for dial tone. Dial Listen for confirmation tone and then hang up. Returning to the Group Lift the handset and listen for dial tone. Dial Listen for confirmation tone and then hang up. 2-24 Voice Terminal Features...
Page 38: Directory 2 - 2
Directory This feature applies to display voice terminals only. The Directory feature allows the user of a voice terminal, where the Display feature is administered, to search the system’s integrated directory for the extension numbers associated with specific names. Information resulting from the use of Directory is displayed on the voice terminal’s screen.
Page 39 If the user reaches the end of a matched list, is displayed. The user can NO MATCH FOUND return to the first matched name by pressing NEXT again. When the displayed name is the correct one, the user can call the number by NOTE: pressing the CALL button.
Page 40 An Example of a Directory Search If you want to check the number for “ Schmid, A”, press . The numbered buttons contain the first two letters of “ Schmid. ” The directory shows you the name and number of the first matched name: D366 Paar, B If you press the next matched name appears:...
Page 41 2-28 Voice Terminal Features...
Page 42: Direct Station Selection 2 - 2
DSS buttons (FLEX DSS) are programmed by the voice terminal user with frequently called PDCs and other System 25 access codes. If the green light is on next to these types of buttons, the user can activate a busy-to-idle reminder. This reminder lets the user know when the call can be made.
Page 43 2-30 Voice Terminal Features...
Page 44: Display 2 - 3
Display This feature applies to display voice terminals only. The Display feature is used in conjunction with several other features of System 25, including: Inside and outside calls Local (time, date, etc. ) functions Programmable buttons and speed dialing codes...
Page 45 Using the Display to Help You Handle Calls Normally, the display is used to check the name/PDC of the caller (internal calls) or the name of the outside line on which the call is coming in (outside calls). Inside Calls. When placing or receiving calls within the system, the display shows the extension number and the name (if the System Administrator has administered this option) of the person calling or the person being called.
Page 46 Conferencing. The display for a conference call is slightly different from the display for an internal or outside call. In the last two positions on the display are the display symbol associated with conference calls, a “ˆ”, and the number of conferees currently in the conference.
Page 47 Account Codes. When entering an account code, the prompt “ ACCT?” and the dialed numbers are displayed, as in the following example. ACCT?3579346 Redirected Calls. If a call is redirected to a voice terminal (that is, sent to a voice terminal because the original voice terminal was busy, the call was unanswered, or one of the features listed in the table on page 2-35 was in effect), the display will have a redirection symbol, a “>”, at the beginning of the display.
Page 48 Display Symbol Summary Display Symbols for Screen 1. The display symbols that apply to positions 1, 15, or 16 of Screen 1 and their meanings are provided in the table below. Location Display symbol Meaning of the symbol Position 1 >...
Page 49 Display Symbols for Screen 2. The display symbols that appear in either position 1 or position 16 of Screen 2 and their meanings are provided in the table below. Location Display symbol Meaning of the symbol Position 1 This string of digits continues from Screen 1. Position 16 This is a Third-Party call.
Page 50 Using the System Directory to Check for a Specific Number The system directory allows for checking the number associated with someone the System 25. For more information about this feature, see the entry for “Directory” on page 2-25. Using the Inspect Button The INSPECT button shows the number and name, if available, associated with an incoming call or a call on hold.
Page 51 2-38 Voice Terminal Features...
Page 52: Exclusion 2 - 3
Exclusion allows users to exclude the attendant and other stations from an existing or held call, or to drop other System 25 users from a call. Exclusion can be applied to only one call at a time. Once Exclusion is invoked on a call it will remain active until the user either presses the button a second time or disconnects the call.
Page 53 2-40 Voice Terminal Features...
Page 54: Following 2 - 4
Following The Following feature allows users who will be away from their own phones to receive calls at another phone. Following differs from Forwarding in that the Following feature is activated from the phone that will be the new, temporary destination for calls, while Forwarding is generally activated from the phone that normally receives the calls.
Page 55 Signing In Your PDC at a Voice Terminal Lift the handset and listen for dial tone. D i a l D i a l y o u r P D C . Dial your PDC again. Listen for confirmation tone and then hang up. Signing Out Your PDC at a Voice Terminal Lift the handset and listen for dial tone.
Page 56 Following, see the entry titled “Following” on page 2-41. Unanswered calls forwarded to a station inside System 25 return to the forwarding station for coverage. Calls forwarded to an outside station that does not answer or is busy do not return to the forwarding station.
Page 57 This procedure can be used from Touch Tone phones only. A person placing a call via the Remote Access feature cannot forward calls to inside stations. Dial the Special Remote Access telephone number. Listen for the brief whistle and dial tone from System 25. Dial your Barrier Code. D i a l Dial your PDC and then listen for confirmation tone.
Page 58: Hfai, Using The Bis Voice Terminal 2 - 4
HFAI, Using the BIS Voice Terminal The Hands-Free Answer on Intercom (HFAI) feature on Built-in-Speakerphone (BIS) voice terminals allows users to answer all inside and some outside calls without lifting the handset. To use this feature, the voice terminal must have an AUTO ANS button assigned to it. The following voice terminals have this feature: 10-Button BIS Voice Terminal 22-Button BIS Voice Terminal...
Page 59 Turning On the HFAI Feature Press [HFAI] The light next to this button turns on. Press [AUTO ANS]. The light next to this button turns on. Answering an Inside Call Listen for the beep that announces a call. The lights next to turn on.
Page 60: Hfai, Using The Hfai Voice Terminal 2 - 4
HFAI, Using the HFAI Voice Terminal The Hands-Free Answer on Intercom (HFAI) feature on the HFAI voice terminal allows users to answer all inside and some outside calls without lifting the handset. To use this feature, a voice terminal must have an AUTO ANS button assigned to it. The types of calls listed in the next table are eligible for HFAI service.
Page 61 Turning On the HFAI Feature 1 Press [HFAI/MIC] The light next to this button turns on. 2 Press [AUTO ANS] The light next to this button turns on. Answering an Inside Call 1 Listen for the beep that announces a call. The light next to [HFAI/MIC] begins to flash.
Page 62: Hfai, Using Voice Terminals With An Hfu 2 - 4
HFAI, Using Voice Terminals With an HFU The Hands-Free Answer on Intercom (HFAI) feature on a voice terminal with a Hands-Free Unit (HFU) allows users to answer all inside and some outside calls without lifting the handset. To use this feature, the voice terminal must have an AUTO ANS button assigned to it.
Page 63 Turning On the HFAI Feature Press [AUTO ANS]. The light next to this button turns on. Answering an Inside Call 1 Listen for the beep that announces a call. The lights next to [MICROPHONE] and [SPEAKERPHONE] on the HFU turn on. 2 Begin speaking.
Page 64: Hfai, Using Voice Terminals Without An Hfu 2 - 5
HFAI, Using Voice Terminals Without an HFU When the Hands-Free Answer on Intercom (HFAI) feature used on the voice terminals listed below (without an attached HFU), callers can “voice announce” their calls. (It is not necessary to lift the handset to hear the caller; however, the handset must be lifted to speak to the caller.
Page 65 Turning On the HFAI Feature Press [ A U T O A N S ] The light next to this button turns on. Answering an Inside Call 1 Listen for the beep that announces a call. The light next to [SPEAKER] turns on. You can hear the caller, but the caller cannot hear you.
Page 66: Hold 2 - 5
Hold This feature allows calls to be held while attending to other matters and then be picked up again. Held calls can be picked up only at the voice terminal that put the call on hold or at a voice terminal that shares the same held line. A held party on an outside line will receive Music-on-Hold, if available.
Page 67 Putting a Call on Hold and Answering Another Call Press [HOLD] The light next to the button of the held call winks. Press the button next to the flashing light. Speak with the caller. To return to the held call, press the button next to the winking light. Single-Line Using the Hold Feature Press the switchhook.
Page 68: Inspect 2 - 5
I n s p e c t This feature applies to display voice terminals only. The Inspect Mode allows display set users to obtain the following information: The PDC and associated name for a call that is either ringing or on hold at a SYSTEM ACCESS or BRIDGED ACCESS button.
Page 69 Determining the Status of Outside Lines Associated with a FACILITY Button. The display shows the number of busy trunks (lines) out of the total number of trunks in the group. In the following example, five out of the 12 trunks in the group are busy. 005 of 012 BUSY Checking the Feature Assigned to a Button.
Page 70: Last Number Dialed 2 - 5
Last Number Dialed This feature applies to multiline voice terminals only. The Last Number Dialed feature automatically stores the last inside or outside number (up to 16 digits), allowing the call to be placed again by pressing the LAST # DIALED button. If the user presses the LAST # DIALED button, then dials additional digits to complete the call, both the currently stored digits and the dialed digits will be stored.
Page 71 Redialing a Telephone Number Lift the handset and listen for dial tone. Press [LAST # DIALED] If you dialed the last telephone number with any of the following NOTE: buttons, you must use the same type of button to obtain dial tone before you redial.
Page 72: Leave Word Calling 2 - 5
Leave Word Calling This feature applies only if a VOICE POWER Voice Messaging System (VMS) has been connected to System 25, and can be used only by individuals who are registered with the VMS system. Leave Word Calling (LWC) enables users to generate “call me” voice messages for PDCs and FPDCs.
Page 73 Multiline Leaving a Message While You Are Active on a Call Press [LEAVE WORD] Listen for confirmation tone and then hang up. Leaving a Message Without Being Active on a Call Lift the handset and listen for dial tone. Press [LEAVE WORD].
Page 74: Local Display Functions 2 - 6
Local Display Functions This feature applies to display voice terminals only. The Local Display feature allows the user to operate the Time/Timer circuit built into the display module. The voice terminal must be in the “Local Mode” for use of Local Display. The Timer has Set, Start, Fwd (Forward), Stop, Rev (Reverse), Time/Timer, and Exit buttons to control the visible clock, calendar, and 60-minute timer displays and an audible alarm.
Page 75 To enter Local Mode, users with a LOCAL button can press LOCAL; users without a LOCAL button press Time/Timer, if not already in Local Mode. The Local Mode will initially display either the Clock/Calendar screen or the Timer screen, depending on which screen was last displayed.
Page 76: Message Waiting 2 - 6
Message Waiting The Message Waiting feature turns on the message waiting light (available on most voice terminals) to indicate there is a message. When attempting to activate a message waiting light on a station that does not have one, reorder tone is heard. A confirmation tone indicates that the message waiting light has been activated.
Page 77 Multiline Turning On a Message Waiting Light While on a Coverage Call Answer the call and take a message. If the light beside the button is off, press [COVER MSG] Hang up. Turning On a Message Waiting Light While Not on a Coverage Call Lift the handset and listen for dial tone.
Page 78: Night Service 2 - 6
Night Service Outside of normal business hours, the system can be set up to provide Night Service. Incoming calls can either activate a bell (or other type of external alert) or ring at specific locations, such as a security desk. Trunk-Answer-From-Any-Station (TAAS) Night Service allows any user to answer a Night Service call by dialing an access code after hearing the external alert.
Page 79 2-66 Voice Terminal Features...
Page 80: Paging 2 - 6
A paging system that is interfaced to System 25 via a ground start trunk port, a loop start trunk port, or an auxiliary trunk port can be administered to be dial restricted. This restricts users from accessing the equipment unless they are assigned DSS buttons with paging access codes.
Page 81 2-68 Voice Terminal Features...
Page 82: Park 2 - 6
Park Park allows calls to be placed on hold and then to be picked up at any voice terminal in the system. It is used in three typical applications: Park A user parks a call, then picks it up at another voice terminal. Meet-Me-Conference A conference member parks the conference, then pages another employee to join the conference.
Page 83 Multiline Parking a Call 1 Press [HOLD] The light next to the button of the held call winks. Press and listen for dial tone. [SYSTEM ACCESS] Dial Listen for confirmation tone and dial tone. 5 If the call is for another party, dial or page that person. Identify the PDC of the voice terminal that parked the call.
Page 84 Single-Line Parking a Call Press the switchhook. Listen for confirmation tone and dial tone. Dial Listen for confirmation tone and dial tone. 5 If the call is for another party, dial or page that person. Identify the PDC of the voice terminal that parked the call. switchhook twice to return If the party does not answer, press the NOTE:...
Page 85 2-72 Voice Terminal Features...
Page 86: Pickup 2 - 7
Group Pickup is assigned to users within a specified group. It allows members to pick up calls from other terminals in the group. System 25 can have a maximum of 16 groups, with up to 16 voice terminals in each group. A user can be assigned to only one Pickup Group.
Page 87 2-74 Voice Terminal Features...
Page 88: Placing Calls 2 - 7
Placing Calls On multiline voice terminals, calls can be placed to other System 25 users inside the company with SYSTEM ACCESS or BRIDGED ACCESS buttons. When placing outside calls, there are four buttons that can be used to obtain outside lines (trunks) on multiline voice terminals:...
Page 89 Placing an Outside Call Using SYSTEM ACCESS or BRIDGED ACCESS 1 Lift the handset and listen for dial tone. If you are using a button to place the call, press NOTE: [BRIDGED ACCESS] the button before you go on to the next step. 2 Dial the outside line access code and listen for dial tone.
Page 90: Placing Data Calls From A Voice Terminal 2 - 7
Placing Data Calls from a Voice Terminal This feature applies to multiline voice terminals only. This feature allows multiline voice terminal users to originate or answer a call at their voice terminals and then establish a data connection by transferring the call to a data terminal. Data terminal calls can be set up from a multiline voice terminal with a DATA button.
Page 91 2-78 Voice Terminal Features...
Page 92: Programming Numbers 2 - 7
Personal Speed Dialing codes (maximum of 25 characters). Single-line voice terminal users can program 20 telephone numbers, account codes, and System Speed Dialing codes into their Personal Speed Dialing codes. System 25 allows these users to program strings of numbers and special characters into the dialing codes.
Page 93 Using * as an Actual Character If you want to use a “*” as an actual character, you must place “ # *” in the stored number. You may want to program the feature access code *70 into a REP DIAL button. You program: # *70 This means: Using # as an Actual Character...
Page 94 Multiline Programming Your Buttons and Personal Speed Dialing Codes Use one of the following procedures to program a new number, to program a new number over an old number, or to remove a previously-stored number. You can program a maximum of: 4 digits in a FLEX DSS button 25 characters in a Personal Speed Dialing code 28 characters into a REP DIAL button...
Page 95 Programming or Removing a Number by Using a Code Lift the handset and listen for dial tone. D i a l Dial the number you want to program. If you want to remove a number, continue to Step 4. 4 To indicate where this number should be stored or removed: Press the button.
Page 96: Recall 2 - 8
Recall Users of single-line voice terminals that have a RECALL button can obtain System 25 recall dial tone by pressing the button. Pressing RECALL is equivalent to briefly pressing and releasing the switchhook (switchhook flash), which is the required method of getting recall dial tone at a terminal not equipped with the RECALL button.
Page 97 2-84 Voice Terminal Features...
Page 98: Remote Access 2 - 8
Remote Access This feature allows a caller to dial into a System 25 from the public network using a predetermined 7- or 10-digit number and use some features and services. The caller may be required to dial a barrier (security) code after reaching the system. Using Remote Access, an employee of a company with a System 25 PBX can access system facilities from home or other remote locations.
Page 99 If you hear fast busy tone, you either dialed NOTE: too slowly or your call was restricted by System 25. From a Dial Pulse (Rotary) Phone Dial the Remote Access number. Listen for the brief whistle and dial tone.
Page 100: Repertory Dialing 2 - 8
Repertory Dialing This feature applies to multiline voice terminals only. Repertory Dialing allows users to program telephone numbers, account codes, or feature access codes into REP DIAL buttons (a maximum of 28 characters). The programmed number can then be dialed by pressing REP DIAL. For details about storing REP DIAL numbers, see the entry for “Programming Numbers”...
Page 101 2-88 Voice Terminal Features...
Page 102: Send All Calls 2 - 8
Send All Calls This feature applies to multiline voice terminals only. The Send All Calls feature allows multiline voice terminal users to turn off their ringers and invoke a “do not disturb” condition toward incoming calls. In addition, users who have coverage or bridged appearances will have those calls directed immediately to their covering and/or bridging stations, without the normal system ringing delay.
Page 103 Using the Send All Calls Feature To turn on the Send All Calls feature: Press [SEND ALL CALLS]. The light next to this button turns on. To turn off this feature: Press again. [SEND ALL CALLS] The light next to this button turns off. 2-90 Voice Terminal Features...
Page 104 Signaling (Manual Signaling) This feature applies to multiline voice terminals only. Multiline voice terminal users can signal another predesignated multiline voice terminal by pressing an associated Manual Signaling (SIGNAL) button. A single tone burst is provided at the signaling terminal. The signaling voice terminal also receives the tone and can use this feature while at any time, whether on-hook or off-hook.
Page 105 2-92 Voice Terminal Features...
Page 106 Speaker This feature applies to multiline voice terminals only. Some multiline voice terminals have a built-in loudspeaker that allows on-hook dialing, group listening, and monitoring of call progress signals. Pressing the SPEAKER button at an idle terminal has the same effect as lifting the handset; the user is connected to the selected call appearance and hears dial tone.
Page 107 2-94 Voice Terminal Features...
Page 108 Speakerphone This feature applies to multiline voice terminals only. System users with a Built-in-Speakerphone (BIS) voice terminal or another type of multiline voice terminal with a Hands-Free Unit (HFU) can use SPEAKERPHONE to place or answer calls without lifting the handset. These units provide two-way communication (listen and talk).
Page 109 2-96 Voice Terminal Features...
Page 110 Speed Dialing Speed dialing allows multiline and single-line voice terminal users to use codes to dial telephone numbers or enter account codes. The system will compare the restrictions applicable for the voice terminal against the number associated with the Speed Dialing code, then allow or deny the call as if the number had been dialed directly from the terminal.
Page 111 2-98 Voice Terminal Features...
Page 112 This feature is not associated with the built-in MESSAGE (or MSG) indicators of many System 25 voice terminals. It lights only the LEDs of the feature buttons assigned to Station- to-Station Message Waiting. No talk path or audible alerting is associated with this feature.
Page 113 2-100 Voice Terminal Features...
Page 114 Testing a Voice Terminal This feature applies to multiline voice terminals only. The lights and ringer on a voice terminal can be tested if the voice terminal has a Test/Program Switch. some voice terminals, the Test/Program switch has a spring. If so, the switch must be held in the “T”...
Page 115 2-102 Voice Terminal Features...
Page 116 Trunk-to-Trunk Transfer is particularly useful when an outside caller requests a transfer to another outside number. In all cases and at all times, either a System 25 station must remain on the call or one of the calls must be an incoming call on a ground start, loop start (administered for trunk-to-trunk transfer), DID, or tie trunk.
Page 117 Multiline Transferring a Call Press and listen for dial [TRANSFER] tone. The light next to the button of the held call winks intermittently. Dial the other party’s PDC or press a line button, for example, [DSS]. If you misdial the number, return to the held party by pressing the NOTE: button next to the winking light.
Page 118 Answering Calls Direct Trunk Attendant Console (DTAC) On a Direct Trunk Attendant Console, trunks terminate on Personal Line buttons, where outside calls are answered and originated. The console can have several incoming calls ringing simultaneously. If a DTAC automatically selects a line when the handset is lifted to place a call, it has been assigned the “prime line preference”...
Page 119 SLAC Typical Displays: type of incoming calls received. The display shows different information, depending on the waiting in the attendant queue. An outside call has arrived at your console. Three calls are OUTSIDE A call from an inside station is directed to the console. The display shows the PDC and name of the calling party.
Page 120 Attendant Message Waiting DTAC and SLAC attendants can use the Attendant Message Waiting feature to turn user station message lights on or off. When the attendant dials a voice terminal, the status of the message light on the attendant console is the same as on the called voice terminal. Each time the attendant presses the ATT MSG button before hanging up, the user’s message light will turn off or on.
Page 121 Turning On a Message Waiting Light Without Ringing the Voice Terminal Lift the handset and listen for dial tone. Press [ATT MSG] The light next to this button turns on. Dial the PDC. Listen for confirmation tone and then hang up. The light next to this button turns off.
Page 122 Automatic Release and Automatic Hold Automatic Release Automatic Release is a standard feature for the DTAC, and can be administered as an optional feature for the SLAC. With Automatic Release, the attendant can extend calls without using the RELEASE button. This feature drops the attendant out of the call when selecting another call appearance button.
Page 123 3-6 Attendant Features...
Page 124 Call Waiting Neither SLACs nor DTACs can have the Call Waiting feature assigned to them. However, other voice terminals in the system may have this feature assigned. If the attendant hears special ringback, it indicates the voice terminal is busy but the called party has been notified of a waiting call.
Page 125 3-8 Attendant Features...
Page 126 C a m p - O n The attendant uses the Camp-On feature to extend a trunk call to a busy voice terminal and allow it to wait (“camp-on”) there. When the attendant camps-on a call, the called-party is notified by a burst of tone heard through the handset: one short tone for an inside call, two short tones for an outside call.
Page 127 3-10 Attendant Features...
Page 128 Cancel The Attendant Cancel feature allows the attendant to terminate an attempt to extend a call and return to the held calling party by pressing one button. If the called party is busy, does not answer, or if the station answers but declines to accept the call, the attendant presses the CANCEL button to return to the calling party.
Page 129 3-12 Attendant Features...
Page 130 Conferencing An attendant can set up a conference that includes System 25 stations as well as outside callers. A conference call can have a maximum of five conferees; however, no more than two of the conferees may be on outside lines. The basic technique for setting up a conference is to start with an established call, then contact the new parties, one at a time, and add them to the conference.
Page 131 Dropping a Conferee When you drop a conferee, anyone added to the conference by the dropped conferee is also dropped. In addition, if you try to drop the person who added you to the conference, you will drop the entire conference. 1 Press [DROP] 2 Press the button of the conferee you want to drop.
Page 132 Typical Displays: Each time a party is called for a conference, the normal information is displayed. Call to an inside station: Asay,J Call to an outside station: 95551634 As each new party is added to the original loop, the display shows the number of conferees (including you) now connected together, along with the current number of calls waiting in the queue.
Page 133 3-16 Attendant Features...
Page 134 A DTAC attendant does not have the option of remaining connected to an extended call. If the attendant extends a call from outside System 25 to a busy voice terminal, the caller will be placed on hold and the called party will hear a tone that indicates they have a waiting (camped-on) call.
Page 135 DTAC and SLAC Extending a Call Using the Attendant Console Press and listen for dial tone. [START] Dial the PDC. If the called party answers and will receive the call, press [RELEASE]. If the called party is busy, does not answer, or will not receive the call, press and speak with the caller.
Page 136 SLAC Switching Between Parties While Extending a Call You can switch back and forth between the caller (source) and the called party (destination) by using buttons. To move between parties: [SOURCE] [DEST] Press to go back to the caller. [SOURCE] The light next to [SOURCE] turns off.
Page 137 Typical Displays: As an example: An outside party has placed a call to you and asks to be connected to Pastorius on extension 372. Four calls are waiting in the attendant queue. Screen 1 has the following information: OUTSIDE After you press to extend the call, Screen 1 changes;...
Page 138 3-5 for more information about these features. If the attendant extends a call from outside System 25 to a busy voice terminal, the caller will be placed on hold and the called party will hear a tone that indicates they have a waiting (camped-on) call.
Page 139 DTAC and SLAC Extending a Call Using the Attendant Console Press and listen for dial tone. [START] Dial the PDC. Press and then hang up. [RELEASE] the DTAC, if the called party does not answer, the call will NOTES: On button.
Page 140 SLAC Typical Displays: Display examples for Extended Calls are shown below. An outside party asks to be connected to B. Taylor on extension 373. Four calls are waiting in the attendant queue. Screen 1 has the following information: OUTSIDE the “&“ symbol indicates that After you press to extend the call, Screen 1 changes;...
Page 141 3-24 Attendant Features...
Page 142 Forced Release This feature applies to Switched Loop Attendant Consoles only. Forced Release drops all active parties from a call in which the attendant and one or more other parties are connected. Non-active parties (such as calls on hold) are not disconnected. Forced Release differs from Release in that Release separates the attendant from an extended call or a conference call, but leaves the other parties connected;...
Page 143 3-26 Attendant Features...
Page 144 Hold This feature allows the attendant to hold calls while attending to other matters and then pick them back up. After putting a call on hold, the handset can be hung up without losing the call. When a call is placed on hold at a SLAC, the system is signaled that the console is available to receive another call;...
Page 145 Putting a Call on Hold and Calling Another Person Press [HOLD] The light next to the button of the held call winks. Press an idle line button. Listen for dial tone. Place and complete the second call. To return to the held call, press the button next to the winking light. Putting a Call on Hold and Answering Another Call Press [HOLD]...
Page 146 J o i n This feature applies to Switched Loop Attendant Consoles only. While extending an incoming call, the Join feature allows the attendant to connect the calling party, the called party, and the console in a three-way call. All parties can talk to each other. Once Join is in use, however, there is no way to “unjoin”...
Page 147 3-30 Attendant Features...
Page 148 Night Service When the attendant leaves for the night, the system can be set so that incoming calls on specified trunks either ring a night bell or are directed to preassigned voice terminals. There are two types of Night Service: Directed Night Service and Trunk-Answer-from-Any- Station (TAAS) Night Service.
Page 149 Trunk-Answer-from-Any-Station (TAAS) Night Service With TAAS Night Service, calls are administered (on a per trunk basis) to activate an external alerting device, such as a bell. Any user can dial the Night Service access code to answer the call. Night Service delay announcement is not available for TAAS Night Service. Using the Night Service Feature To turn on Night Service: Press...
Page 150 P a g i n g For this feature to work, a paging system must be installed on the System 25. The attendant can then access the paging system by pressing a PAGE button or by dialing a paging access code.
Page 151 3-34 Attendant Features...
Page 152 Park Parked calls are like held calls except they can be picked up from any voice terminal. Any call can be parked on an Attendant Console, but only one call can be parked at a time. If Selector Consoles are used, the System Administrator may assign up to eight of the buttons to the Park feature, allowing eight calls to be parked simultaneously.
Page 153 Parking a Call on the Selector Console Press the Group Select and DXS buttons for one of the Park codes. For example, if one of the Park codes is 801, press Group Select button 8 and then press DXS button 01. Listen for confirmation tone.
Page 154 Placing Calls DTAC and SLAC attendants use the following buttons to place calls to people inside and outside the company: Attendant Console Button Type of Call DTAC inside or outside calls [BRIDGED ACCESS] inside or outside calls [SYSTEM ACCESS] outside calls [PERS LINE] SLAC inside or outside calls...
Page 155 Placing an Outside Call Using SYSTEM ACCESS or BRIDGED ACCESS Lift the handset and listen for dial tone. If you are using a button to place the call, press NOTE: BRIDGED ACCESS the button before you go on to the next step. Dial the outside line access code and listen for dial tone.
Page 156 SLAC Placing an Inside Call Using the SLAC Lift the handset and listen for dial tone. The light next to the selected [LOOP] button turns on. Dial the PDC. Placing an Outside Call Lift the handset and listen for dial tone. The light next to the selected [LOOP] button turns on.
Page 157 Placing an Outside Call for Someone and Calling the Party Back Lift the handset and listen for dial tone. Dial the outside call. Announce the call. Press and listen for dial tone. [START] Dial the person for whom you placed the call and announce the call. Press and then hang up.
Page 158 Position Busy An attendant can use POS BUSY to send most calls that come to the attendant console to the other attendant, or (SLAC only) to a designated “backup” station. Only one attendant console can be placed in Position Busy mode at a time. DTAC For DTAC systems, POS BUSY can only be used when there are two attendant consoles.
Page 159 S L A C To use Position Busy, a system with a SLAC(s) must have either two attendant positions or one position and a multiline voice terminal administered as a “backup.” If the system has two consoles, pressing POS BUSY on one console will make it inactive and cause most calls in the common queue to be directed to the active console.
Page 160 Release Release is used when the attendant extends calls. It releases the attendant from the connection to the calling and called parties and completes the call transfer. There are two types of Release: Manual and Automatic. Manual Release: The attendant presses RELEASE to invoke the feature. Automatic Release: Simplifies the attendant procedures by eliminating the need for pressing RELEASE while extending calls.
Page 161 3-44 Attendant Features...
Page 162 Return Coverage on Busy Return Coverage on Busy returns to the attendant, after a specified time period, an unanswered camped-on call. If Attendant Camp-On is not provided (that is, Camp-On return time is administered to be zero seconds), calls released by the attendant to busy voice terminals return to the console immediately.
Page 163 3-46 Attendant Features...
Page 164 Return Coverage on Don't Answer Attendant Return Coverage on Don't Answer allows unanswered calls extended by the attendant to be returned to the attendant for additional service. Calls that are not answered after a specified number of rings return to the RTN-DA buton on the DTAC, or to a LOOP button on the SLAC.
Page 165 3-48 Attendant Features...
Page 166 Source and Destination This feature applies to Switched Loop Attendant Consoles only. Attendant Source and Destination allows the SLAC attendant, while extending a call, to switch back and forth between the calling party (the source) and the called party (the destination) before connecting them together. For more information, see the entry for “Extending Calls (Announced)”...
Page 167 3-50 Attendant Features...
Page 168 Splitting One-Way Automatic Attendant Splitting One-Way Automatic is a standard step in call extending procedures. It allows the attendant to converse privately with a called party while the calling party is on hold. Splitting occurs when the attendant presses START or a Selector Console button.
Page 169 3-52 Attendant Features...
Page 170 Start The START button is used by both the SLAC and DTAC attendants to extend calls from the console. On the Selector Console, the attendant just presses the appropriate Group Select and DXS buttons. For more information on using the START button, see the entries for “Extending Calls” on pages 3-17 and 3-21.
Page 171 3-54 Attendant Features...
Page 172 The System Alarm feature provides an alarm on the attendant console to alert the attendant to problems detected by the system software. When the green light next to the ALARM button flashes, there is a problem with the System 25 software. If this occurs, the AT&T Systems Technician should be notified at once.
Page 173 3-56 A t t e n d a n t F e a t u r e s...
Page 174 Testing the Consoles The attendant can test the lights and ringer on the attendant console and the lights on the selector console. On some DTACs, the Test/Program switch has a spring. If so, the switch must be held in the “T” position to test the lights and ringer; the switch will automatically return to the midpoint when it is released.
Page 175 This section discusses data terminals or PCs connected to System 25 data ports via data modules (ADUs). The procedures in this section explain how to use a data terminal to make System 25 data and voice calls, and how to change the options associated with the System 25 data port.
Page 176 Expert Mode Expert Mode can be used to perform Command In addition to the Command Mode menu, Mode functions. When in Expert Mode, a command prompt is displayed, but there are no menus. By eliminating menus, multiple commands can be entered on a single line. Expert Mode is intended to be used primarily in command scripts and computer programs.
Page 177 Making a Data Call with a Data Terminal When a data call is made from a data terminal, voice terminal dialing is replaced by keyboard dialing and call progress tones are replaced by call progress messages. A DIAL: message prompts the user to enter the called number from the keyboard. When the message appears, this indicates the dialed number RINGING...
Page 178 Making a Data Call With a Data Terminal 1 Turn on the terminal. Press and then press [BREAK] [RETURN] The Command Mode menu is displayed. Select <Data call> . The following prompt is displayed: DIAL: Enter the number for the data endpoint and press [RETURN] When the connection is made, the following message is displayed: CONNECTED, SPEED = xxx...
Page 179 Making a Data Call with a Voice Terminal Transfer to Data With this feature, a multiline voice terminal user can originate or answer a call, then establish a data connection by transferring the call to a data terminal. A voice terminal must have a DATA feature button (Transfer to Data) to use this feature. The DATA button is associated with the Data Dial Code (DDC) of a specific digital data endpoint.
Page 180 Data Terminal Features...
Page 181 Allows two data endpoints to communicate at different rates. Local Echo Determines whether characters from the data equipment will be echoed by System 25 during Command Mode. Answer Text Enables call progress messages to be displayed at the called data endpoint.
Page 182 Viewing Data Port Options Turn on the data terminal. Press and then press [BREAK] [RETURN] The Command Mode menu is displayed. Select <Options> . A sub-menu is displayed. Select <View options> . The current options are displayed. Modifying Data Port Options 1 Turn on the data terminal.
Page 183 Move the cursor to the speed to be changed. To add the speed, type a + (plus). To remove the speed, type a – (minus). want the System 25 data port to autobaud to your data NOTE: terminal speed, add Auto (by typing a + beneath it.) Making sure the cursor is not under “...
Page 184 4-10 Data Terminal Features...
Page 185 Third-Party Call Setup Using a Data Terminal Third-Party Call Setup allows a data terminal (the third party) in Command Mode to set up a call between an on-premises voice or data terminal (the source) and another voice or data terminal (the destination), which can be on- or off-premises. Once the call has been set up, the third party drops off and is not included in the call.
Page 186 Setting Up a Third-Party Call Turn on the data terminal. Press and then press [BREAK] [RETURN] The Command Mode menu is displayed. Select <Voice call> . The following prompt is displayed: DIAL: Enter the destination number, followed by and then the PDC or DDC of the terminal for which the call is being set up (the source), as in the following example: 5551704 F 403...
Page 187 The following procedure describes how to make a data call if the data terminal is connected to a System 25 data port a host computer is to be accessed on the STARLAN NETWORK. This procedure assumes the caller is using either a data terminal, a PC running terminal emulation software such as the AT&T System 25 Communication Access Manager (CAM),...
Page 188 Making a Data Call from the STARLAN NETWORK to System 25 The following procedure assumes the PC originating the data call is: Connected to the STARLAN NETWORK Running the STARLAN NETWORK client software Loaded with NAUCOM Running the CAM or 4410 Terminal Emulator software...
Page 189 Ending a Data Call If the PC is connected to System 25 over a STARLAN NETWORK, do not turn off or reboot the PC to end the call. If you do, the call will remain connected for another fifteen (15) minutes.
