Chapter 2: Jumpers and Connectors

Internal Connectors

debug Connector

Connector type: 1x10 10-pin header, 1.0mm pitch
Connector location: DB1
1 1 1 0
10
Pin definition
1 GND
3 LPC_CLK
5 LPC_LAD3
7 LPC_LAD1
9 LPC_SERIRQ
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
Pin definition
2 LPC_PLTRST#
4 LPC_LFRAME#
6 LPC_LAD2
8 LPC_LAD0
10 +3.3V

LEd Connector

Connector type: 1x5 5-pin header, 2.0mm pitch
Connector location: WLED1
5 1
Pin definition
1 HDD_LED-
3 GND
5 POWER_LED+
17
Pin definition
2 HDD_LED+
4 STBY_LED+
6
