Chapter 2: Jumpers and Connectors
Jumpers
LVdS Panel Power Selection
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JPNL_PWR1
1
3
Pin
Settings
1-2 On
+3V3
2-3 On
+5V
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
Backlight Volume Selection
Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JBLT_PWM1
1
3
Pin
Settings
1-2 On
+3V3
2-3 On
+5V
