Chapter 2: Jumpers and Connectors

COM2 Port Power Setting

Connector type: 2x3 6-pin header, 2.0mm pitch
Connector location: JCOM2_RI1
2
6
1
5
Pin
Settings
1-2 On
+12V
3-4 On
Ring
5-6 On
+5V
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
12
NISE 108 User Manual
