LVdS Inverter Connector

Connector type: 1x7 7-pin header, 2.5mm pitch
Connector location: INV1
7 1
Pin definition
1 +5V
3 +12V
5 GND
7 BKLEN
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
Pin definition
2 +12V
4 BKCTRL
6 GND

Front Panel Connector

Connector type: 2x7 14-pin header, 2.0mm pitch
Connector location: FRONT1
2 14
1 13
Pin definition
1 PWR_LED#
3 HDD_LED#
5 MAIN_SMBCLK
7 MAIN_SMBDATA
9 SLP_S3#
11 PWR_BTN#
13 RST _BTN#
19
Pin definition
2 PWR_LED
4 HDD_LED
6 +3V3
8 GND
10 PS_ON
12 GND
14 GND
