Front Connector Configuration

Overview
The following tables list the pin configuration of the connectors X4 to X7.
Connector X4
Pin No. Name
1 NC Not assigned
2 S1+ Analog output Channel 1
3 S2+ Analog output Channel 2
4 S3+ Analog output Channel 3
5 S4+ Analog output Channel 4
6 S5+ Analog output Channel 5
7 S6+ Analog output Channel 6
8 S7+ Analog output Channel 7
9 S8+ Analog output Channel 8
10 M Signal common AO / AI
Connector X5
Pin No. Name
1 NC Not assigned
2 M5+ Analog input Channel 5+
3 M5– Analog input Channel 5–
4 M6+ Analog input Channel 6+
5 M6– Analog input Channel 6–
6 M7+ Analog input Channel 7+
7 M7– Analog input Channel 7–
8 M8+ Analog input Channel 8+
9 M8– Analog input Channel 8–
10 M Signal common AI
AddFEM
C79000–G8076–C900–03
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Function Pin No.
11
12
13
14
15
16
17
18
19
20
Function Pin No.
11
12
13
14
15
16
17
18
19
20
Name Function
NC Not assigned
M1+ Analog input Channel 1+
M1– Analog input Channel 1–
M2+ Analog input Channel 2+
M2– Analog input Channel 2–
M3+ Analog input Channel 3+
M3– Analog input Channel 3–
M4+ Analog input Channel 4+
M4– Analog input Channel 4–
M Signal common AI
Name Function
NC Not assigned
M9+ Analog input Channel 9+
M9– Analog input Channel 9–
M10+ Analog input Channel 10+
M10– Analog input Channel 10–
M11+ Analog input Channel 11+
M11– Analog input Channel 11–
M12+ Analog input Channel 12+
M12– Analog input Channel 12–
M Signal common AI
A
A-1
