Commissioning / Operation / Maintenance
Parameters
The FEM_AO has the following input parameters:
Table 5-9 Input parameters of the FEM_AO
Parameter Comment
BLOCKCON Block connector
AO1_VAL Analog Output 1 Value
AO1_HRNG Analog Output 1 High Range
AO1_LRNG Analog Output 1 Low Range
AO1_SIM Simulation Value Analog Output 1
SIMUL1 1 = Simulation on
AO2_VAL Analog Output 2 Value
AO2_HRNG Analog Output 2 High Range
AO2_LRNG Analog Output 2 Low Range
AO2_SIM Simulation Value Analog Output 2
SIMUL2 1 = Simulation on
AO3_VAL Analog Output 3 Value
AO3_HRNG Analog Output 3 High Range
AO3_LRNG Analog Output 3 Low Range
AO3_SIM Simulation Value Analog Output 3
SIMUL3 1 = Simulation on
AO4_VAL Analog Output 4 Value
AO4_HRNG Analog Output 4 High Range
AO4_LRNG Analog Output 4 Low Range
AO4_SIM Simulation Value Analog Output 4
SIMUL4 1 = Simulation on
AO5_VAL Analog Output 5 Value
AO5_HRNG Analog Output 5 High Range
AO5_LRNG Analog Output 5 Low Range
AO5_SIM Simulation Value Analog Output 5
SIMUL5 1 = Simulation on
AO6_VAL Analog Output 6 Value
AO6_HRNG Analog Output 6 High Range
AO6_LRNG Analog Output 6 Low Range
AO6_SIM Simulation Value Analog Output 6
SIMUL6 1 = Simulation on
AO7_VAL Analog Output 7 Value
AO7_HRNG Analog Output 7 High Range
AO7_LRNG Analog Output 7 Low Range
AO8_SIM Simulation value output 7
SIMUL7 1 = Simulation on
5-54
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Data type Visible Default
STRUCT Yes 0
REAL Yes 0.0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 0.0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 0.0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0.0
REAL Yes 0.0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 0.0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 0.0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
REAL Yes 0.0
REAL Yes 100.0
REAL Yes –100.0
REAL No 0.0
BOOL No 0
