1 Introduction

1.1 Purpose of the Operating Instructions

This instruction manual provides information for safe instal-
lation and commissioning of the adjustable frequency
drive.
This instruction manual is intended for use by qualified
personnel.
Read and follow the instruction manual to use the
adjustable frequency drive safely and professionally, and
pay particular attention to the safety instructions and
general warnings. Keep this instruction manual available
with the adjustable frequency drive at all times.
®
VLT is a registered trademark.

1.2 Additional Resources

Other resources are available to understand advanced
frequency converter functions and programming.
•
The VLT
provides greater detail on working with
parameters and many application examples.
•
The VLT
provides detailed information about capabilities
and functionality to design motor control
systems.
•
Instructions for operation with optional
equipment.
Supplementary publications and manuals are available
from Danfoss. See www.danfoss.com/BusinessAreas/DrivesSo-
lutions/Documentations/VLT+Technical+Documentation.htm
for listings.

1.3 Document and Software Version

This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Please send
suggestions via email to
techcom_change_request@danfoss.com, including a
reference to the document version.
Table 1.1 shows the document version and the
corresponding software version.
Edition
MG20MCxx
Table 1.1 Document and Software Version
4
VLT
®
AQUA Drive FC 202 Programming Guide
®
AQUA Drive FC 202 Design Guide
Remarks Software version
Replaces MG20MBxx
Danfoss A/S © 01/2015 All rights reserved.
®
AQUA Drive FC 202

1.4 Product Overview

1.4.1 Intended Use
The frequency converter is an electronic motor controller
intended for:
•
Regulation of motor speed in response to system
feedback or to remote commands from external
controllers. A power drive system consists of the
frequency converter, the motor, and equipment
driven by the motor.
•
System and motor status surveillance.
Depending on configuration, the frequency converter can
be used in standalone applications or form part of a larger
appliance or installation.
The frequency converter is allowed for use in residential,
industrial, and commercial environments in accordance
with local laws, standards, and emission limits as described
in the design guide.
Single phase frequency converters (S2 and S4) installed
in the EU
The following limitations apply:
•
Units with an input current below 16 A and an
input power above 1 kW are only intended for
professional use in trades, professions, or
industries and not for sale to the general public.
•
Designated application areas are public pools,
public water supplies, agriculture, commercial
buildings, and industries. All other single phase
units are only intended for use in private low-
voltage systems interfacing with public supply
only at a medium or high voltage level.
•
Operators of private systems must ensure that
the EMC environment complies with IEC
610000-3-6 and/or the contractual agreements.
NOTICE!
In a residential environment, this product can cause
radio interference, in which case supplementary
mitigation measures may be required.
Foreseeable misuse
Do not use the frequency converter in applications, which
2.x
are non-compliant with specified operating conditions and
environments. Ensure compliance with the conditions
specified in chapter 8 Specifications.
