Danfoss VLT AQUA Drive FC 202 Operating Instructions Manual page 19

Electrical Installation
1
9
10
L1
L2
L3
PE
1 PLC
2 Frequency converter
3 Output contactor
4 Grounding rail (PE)
5 Cable insulation (stripped)
Figure 4.2 EMC-compliant Electrical Connection
MG20MC22
Operating Instructions
2
11
8
6
6 Cable gland
7 Motor, 3-phase and PE
8 Mains, 3-phase and reinforced PE
9 Control wiring
10
Equalising min. 16 mm
Danfoss A/S © 01/2015 All rights reserved.
3
4
u
v
w
PE
7
2 (0.025 in 2 )
4 4
5
17
