How to Programme
5.10 Parameters: 40-** Mains / Filter
5.10.1 40-0* Mains Data
40-00 Mains Voltage
Range:
630 V [[525-690 V]]
*
40-01 Mains Frequency
Option:
[0] 50 Hz
*
5 5
[1] 60 Hz
40-02 Mains Inductance
Range:
0.039 mH [0.000 - 65.000
*
mH]
40-03 Mains Resistance
Range:
0.50 mOhm
*
mOhm]
5.10.2 40-1* LCL Filter
40-10 Mains Side Inductance (Lm)
Range:
0.029 mH [0.000 - 65.000 mH] Set the main side inductance of
*
40-11 Mains Side Resistance
Range:
0.19 mOhm
*
mOhm]
40-12 Converter Side Inductance (LC)
Range:
0.100 mH [0.000 - 65.000 mH] Set the converter side
*
40-13 Converter Side Resistance (RC)
Range:
0.48 mOhm
*
mOhm]
40-14 Filter Capacity
Range:
400 uF [0 - 65000 uF]
*
52
Function:
Set the mains voltage line to line.
Function:
Set the mains nominal frequency.
Function:
Set the Inductance of the mains.
This could be the transformer.
Function:
[0.00 - 650.00 Set the value of the mains
resistance. This could be the
transformer.
Function:
the LCL filter.
Function:
[0.00 - 650.00 Set the main side resistance
of the LCL filter.
Function:
inductance of the LCL filter.
Function:
[0.00 - 650.00 Set the converter side
resistance of the LCL filter.
Function:
Set the capacity of the LCL filter.
