How to Programme
5-14 Terminal 32 Digital Input
Option:
[0] No operation
*
[1] Reset
[8] Start
[23] Set-up select bit 0 Select Set-up select bit 0 or Select Set-
*
[24] Set-up select bit 1 (Default Digital input 32): Same as Set-
*
5 5
5-15 Terminal 33 Digital Input
Option:
[0] No operation
*
[1] Reset
[8] Start
[23] Set-up select bit 0 Select Set-up select bit 0 or Select Set-
*
[24] Set-up select bit 1 (Default Digital input 32): Same as Set-
*
5.4.2 5-3* Digital Outputs
Parameters for configuring the output functions for the
output terminals. The 2 solid-state digital outputs are
common for terminals 27 and 29. Set the I/O function for
terminal 27 in par. 5-01 Terminal 27 Mode, and set the I/O
function for terminal 29 in par. 5-02 Terminal 29 Mode. These
parameters cannot be adjusted while the AFE is running.
5-30 Terminal 27 Digital Output
Option:
[0] No operation
[1] Control ready
[2] Drive ready
[9] Alarm
[254] Soft charge ready DC bus charged
[255] DC-link on ref.
*
40
®
VLT Active Front End AFE 302 Operating Instructions Liebherr
Function:
up select bit 1 to select one of the four
set-ups. Set0-10 Active Set-up to Multi
Set-up.
up select bit 0 [23].
Function:
up select bit 1 to select one of the four
set-ups. Set0-10 Active Set-up to Multi
Set-up.
up select bit 0 [23].
Function:
Default for all digital outputs and relay
outputs
The control board receives supply
voltage.
The frequency converter is ready for
operation and applies a supply signal
on the control board.
An alarm activates the output. There
are no warnings.
AFE running and motor operation
allowed.
MG.33.X2.02 - VLT
5-31 Terminal 29 Digital Output
Option:
[0] No operation
*
[1] Control ready
[2] Drive ready
[9] Alarm
[254] Soft charge ready DC bus charged
[255] DC-link on ref.
In this parameter, the function for the terminal 29 digital
output is selected.
5.4.3 5-4* Relays
Parameters for configuring the timing and the output
functions for the relays
(Relay 1 [0], Relay 2 [1])
5-40 Function Relay
Option:
[0] No operation
[1] Control ready
[2] Drive ready
[9] Alarm
[254] Soft charge ready DC bus charged
*
[255] DC-link on ref.
In this parameter, the function for the relay outputs is
selected. The selection of each mechanical relay is realised in
an array parameter.
5-41 On Delay, Relay
Range:
0.01 s [0.01 - 600.00
*
s]
5-42 Off Delay, Relay
Range:
0.01 s [0.01 - 600.00
*
s]
®
