How to Programme
5.2.3 0-2* LCP Display
Parameters used to select what kind of information (e.g.
power, current, frequency) should be displayed in the
STATUS window.
0-20 Display Line 1.1 Small
Option: Function:
Select a variable for display in line 1,
left position.
[0] None No display value selected.
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word Present control word
[1603] Status Word Present status word.
[1630] DC Link Voltage Intermediate circuit voltage in the AFE.
[1634] Heatsink Temp. Present heat sink temperature of the
AFE. The cut-out limit is 95 ±5°C;
cutting back in occurs at 70 ±5°C.
[1635] Inverter Thermal Percentage load of the inverters.
[1636] Inv. Nom. Current Nominal current of the AFE.
[1637] Inv. Max. Current Maximum current of the AFE.
[1639] Control Card Temperature of the control card.
Temp.
[1641] Current Value of measured current
[1642] Voltage Shows the actual mains voltage, when
the AFE is running.
[1643] Frequency Returns the actual mains frequency,
when the AFE is running.
[1644] Power [kW] Returns the calculated mains power in
kW
[1645] Power [hp] Returns the calculated mains power in
HP.
[1660] Digital Input Signal states form the 6 digital
terminals (18, 19, 27, 29, 32 and 33).
Input 18 corresponds to the bit at the
far left. Signal low = 0; Signal high = 1.
[1666] Digital Output Binary value of all digital outputs.
[bin]
[1680] Fieldbus CTW 1 Control word (CTW) received from the
Bus Master.
[1682] Fieldbus REF 1 Main reference value sent with control
word from the Bus Master.
[1684] Comm. Option Extended fieldbus communication
STW option status word.
[1685] FC Port CTW 1 Control word (CTW) received from the
Bus Master.
[1686] FC Port REF 1 Status word (STW) sent to the Bus
Master.
[1690] Alarm Word One or more alarms in a Hex code.
[1691] Alarm Word 2 One or more alarms in a Hex code.
[1692] Warning Word One or more warnings in a Hex code.
[1693] Warning Word 2 One or more warnings in a Hex code.
[1694] Ext. Status Word One or more status conditions in a Hex
code.
®
VLT Active Front End AFE 302 Operating Instructions Liebherr
0-21 Display Line 1.2 Small
Option:
[1641]
0-22 Display Line 1.3 Small
Option:
[1644]
0-23 Display Line 2 Large
Option:
[1643]
0-24 Display Line 3 Large
Option:
[1630]
0-25 My Personal Menu
Range:
Application
dependent
®
MG.33.X2.02 - VLT is a registered Danfoss trademark
Function:
Mains Current Select a variable for display in line 1,
*
[A] middle position. The options are the
same as listed for par. 0-2*.
Function:
Power [kW] Select a variable for display in line 1, right
*
position. The options are the same as listed
for par. 0-2*.
Function:
Frequency [Hz] Select a variable for display in line 2. The
*
options are the same as those listed for
par. 0-2*.
Function:
Select a variable for display in line 2.
Counter [kWh]
*
The options are the same as those listed
for par. 0-20 Display Line 1.1 Small.
Function:
[0 - Define up to 50 parameters to appear in
9999 ] the Q1 Personal Menu, accessible via the
*
[Quick Menu] key on the LCP. The
parameters will be displayed in the Q1
Personal Menu in the order they are
programmed into this array parameter.
Delete parameters by setting the value to
'0000'.
For example, this can be used to provide
quick, simple access to just one or up to
50 parameters which require changing on
a regular basis (e.g. for plant maintenance
reasons) or by an OEM to enable simple
commissioning of their equipment.
