Danfoss VLT AFE 302 Operating Instructions Manual page 49

How to Programme
15-21 Historic Log: Value
Array [50]
Range:
0 N/ [0 -
A 2147483647 N/
*
A]
5 5
15-22 Historic Log: Time
Array [50]
0 [0 - 2147483647 s] View the time at which the logged event
*
5.8.3 15-3* Alarm Log
Parameters in this group are array parameters, where up to
10 fault logs can be viewed. [0] is the most recent logged
data, and [9] the oldest. Error codes, values, and time stamp
can be viewed for all logged data.
15-30 Fault Log: Error Code
Array [10]
Range:
0 [0 - 255 ] View the error code and look up its meaning in the
*
48
VLT
Function:
View the value of the logged event.
Interpret the event values according to
this table:
Digtal input Decimal value. See
16-60 Digital Input for
description after
converting to binary
value.
Digital output Decimal value. See
(not 16-66 Digital Output [bin]
monitored in for description after
this SW converting to binary
release) value.
Warning Decimal value. See
word 16-92 Warning Word for
description.
Alarm word Decimal value. See
16-90 Alarm Word for
description.
Status word Decimal value. See
16-03 Status Word for
description after
converting to binary
value.
Control word Decimal value. See
16-00 Control Word for
description.
Extended Decimal value. See
status word 16-94 Ext. Status Word for
description.
occurred. Time is measured in ms since
frequency converter start.
Function:
Troubleshooting chapter of the FC 300 Design
Guide.
MG.33.X2.02 - VLT
®
Active Front End AFE 302 Operating Instructions Liebherr
15-31 Alarm Log: Value
Array [10]
Range:
0 N/A [-32767 - 32767
*
N/A]
15-32 Fault Log: Time
Array [10]
0 [0 - 2147483647 s] View the time when the logged event
*
5.8.4 15-4* Drive Identification
Parameters containing read only information about the
hardware and software configuration of the AFE.
15-40 AFE Type
Option: Function:
View the AFEtype. The read-out is identical to the FC 300
Series power field of the type code definition, characters
1-6.
15-41 Power Section
Option: Function:
View the AFE type. The read-out is identical to the FC 300
Series power field of the type code definition, characters
7-10.
15-42 Voltage
Option: Function:
View the AFE type. The read-out is identical to the FC 300
Series power field of the type code definition, characters
11-12.
15-43 Software Version
Range:
0 N/A [0 - 0 N/A] View the combined SW version (or 'package
*
®
is a registered Danfoss trademark
Function:
View an extra description of the error.
This parameter is mostly used in
combination with alarm 38 'internal
fault'.
occurred. Time is measured in seconds
from frequency converter start-up.
Function:
version') consisting of power SW and control
SW.
