How to Programme
16-66 Digital Output [bin]
Range: Function:
0 [0 - 15 ] View the binary value of all digital outputs.
*
5.9.4 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control
words.
16-80 Fieldbus CTW 1
Range: Function:
0 N/A [0 - 65535 View the two-byte Control word (CTW)
*
N/A] received from the Bus-Master. Interpretation
of the Control word depends on the fieldbus
option installed and the Control word profile
selected in 8-10 Control Profile.
For more information please refer to the
relevant fieldbus manual.
16-82 Fieldbus REF 1
Range: Function:
0 N/A [-200 - 200 View the two-byte word sent with the
*
N/A] control word form the Bus-Master to set the
reference value.
For more information please refer to the
relevant fieldbus manual.
16-84 Comm. Option STW
Range: Function:
0 N/A [0 - 65535 N/A] View the extended fieldbus comm.
*
option status word.
For more information please refer to the
relevant fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
0 N/A [0 - 65535 N/ View the two-byte Control word (CTW)
*
A] received from the Bus-Master. Interpre-
tation of the control word depends on the
fieldbus option installed and the Control
word profile selected in 8-10 Control
Profile.
16-86 FC Port REF 1
Range: Function:
0 N/A [-200 - 200 View the two-byte Status word (STW) sent
*
N/A] to the Bus-Master. Interpretation of the
Status word depends on the fieldbus option
installed and the Control word profile
selected in 8-10 Control Profile.
®
VLT Active Front End AFE 302 Operating Instructions Liebherr
5.9.5 16-9* Diagnosis Read-Outs
16-90 Alarm Word
Range:
0 N/A
16-91 Alarm Word 2
Range:
0
*
16-92 Warning Word
Range:
0 N/A
16-93 Warning Word 2
Range:
0
*
16-94 Ext. Status Word
Range:
0
*
®
MG.33.X2.02 - VLT is a registered Danfoss trademark
Function:
[0 - 4294967295 N/A] View the alarm word sent via the
*
serial communication port in hex
code.
Function:
[0 - 4294967295 ] View the alarm word sent via the serial
communication port in hex code.
Function:
[0 - 4294967295 N/A] View the warning word sent via
*
the serial communication port in
hex code.
Function:
[0 - 4294967295 ] View the warning word sent via the serial
communication port in hex code.
Function:
[0 - 4294967295 ] Returns the extended warning word sent
via the serial communication port in hex
code.
