Supported Optional VDCP Commands(Continued)
Command
3x.02 - NEXT
3x.05 - PORT STATUS
REQUEST
3x.06 - POSITION
REQUEST
3x.08 - DEVICE TYPE
REQUEST
3x.10 - SYSTEM STATUS
REQUEST
3x.11 - ID LIST
3x.14 - ID SIZE REQUEST This command returns the duration of the specified ID to the controller. The
3x.16 - ID REQUEST
Description
The NEXT command is used to transfer any remaining IDs in groups of up to
ten. It has the same format as LIST commands and NEXT is called repeatedly
until all IDs have been transferred. See the LIST command 3X.11 for more
details.
The Port Status command returns to the controller the status bytes specified for
the selected video port, preceded by the bit map.
The POSITION REQUEST query returns the current position 'timecode' or
time remaining within the ID which is currently playing on the selected port.
The selected port must be in PLAY, RECORD, CUED, OR STILL state or an
error will be logged. An error condition will result in the appropriate bit being
set in the port status error bytes. The POSITION/TIME returned is in RETURN
DATA 2-5 in FRAMES, SEC, MIN, HOURS BCD format is preceded by
RETURN DATA 1 the time type.
The DEVICE TYPE REQUEST command is used to request the specifications
of the Controlled Device. The response to this command is a 16-byte
(maximum) data message advising of the specifications of the CONTROLLED
DEVICE. The first N bytes will be the manufacturer ID followed by a colon ':'
This command returns to the controller information about the MAIN storage
system.This command returns to the controller information about the MAIN
storage system
This command returns a list of all IDs currently stored on the system to the
controller. The format will return the number of IDs remaining to be transmitted
in subsequent transmissions in RETURN DATA 1 and RETURN DATA 2
(RETURN DATA 1 MSB, RETURN DATA 2 LSB), followed by ten 8 byte IDs
in RETURN DATA 3 to RETURN DATA 82. The NEXT command is used to
transfer any remaining IDs in groups of up to ten. NEXT is called repeatedly
until all IDs have been transferred.
format returns the frames in RETURN DATA 1, seconds in RETURN DATA 2,
minutes in RETURN DATA 3 and hours in RETURN DATA 4, in BCD. SEND
DATA 1-8 contains the ID name. This command returns the duration of the
specified ID to the controller. The format returns the frames in RETURN DATA
1, seconds in RETURN DATA 2, minutes in RETURN DATA 3 and hours in
RETURN DATA 4, in BCD. SEND DATA 1-8 contains the ID name.
This command tells the controller whether the ID is currently in the 'get from
archive list' for the selected port and whether the ID is currently in the disk and
the ARCHIVE. This command allows the automation controller to ask if an ID
it needs for future playout is in the DISK or ARCHIVE. This command tells the
controller whether the ID is currently in the 'get from archive list' for the
selected port and whether the ID is currently in the disk and the ARCHIVE.
This command allows the automation controller to ask if an ID it needs for
future playout is in the DISK or ARCHIVE.
