Command Line Interface (CLI)
With the function "LED-Panel.exe -getDisplayBrightness" it is possible to read the intensity of
the backlight illumination of the LCD display.
Return Parameters
After the execution of the function "LED-Panel.exe -getDisplayBrightness" the device will
return a one-, two- or three-digits value of the backlight intensity in %.
For instance:
Return value 27 means that the intensity of the backlight is 27%.
Return value 0 means that the backlight is turned OFF.
Return value 100 means that the intensity of the backlight is 100%.
6.2.21 Set the Direction of the LEDs for "Response Time" and "Exposure
Time" Modes
Function
setDirectionSingle <X>
Description
"LED-Panel.exe -setDirectionSingle <X>" switches the desired moving direction of LEDs.
There are eight possible directions.
Parameters
<X> Description
1 Starting from the top left, run from left to right and to the bottom
2 Starting from the top right, run from right to left and to the bottom
3 Starting from the bottom left, run from left to right and to the top
4 Starting from bottom right, run from right to left and to the top
5 Starting from top left, run from top to bottom and to the right
6 Starting from top right, run from top to bottom and to the left
7 Starting from bottom left, run from bottom to top and to the right
8 Starting from bottom right, run from bottom to top and to the left
Table 8
