Measurement methods
Figure 6
Figure 5
The frequency of the LED-Panel does not match
The frequency of the LED-Panel matches the
the frame rate of the camera (flickering LEDs)
frame rate of the camera (LEDs glow
permanently)
4.5 Speed of multi shot mode
The speed of the multi shot mode of cameras can also be measured with the aid of the LED-
Panel. The LED-Panel must be set into the operating mode CONTINOUS and the time must be
defined. Afterwards pictures of the LED-Panel are taken in the multi shot mode. The speed of
multi shot mode can be calculated from the distance between the turned on LEDs in two
consecutive pictures.
Figure 8
Figure 7
14
Figure 10
Figure 9
