FC 300 Design Guide
Mechanical Installation
Accessory Bag
Find the following parts included in the FC 100/
300 Accessory Bag.
Frame sizes A1, A2 and A3
IP20/Chassis
Frame sizes B1 and B2
IP21/IP55/Type 1/Type 12
1 + 2 only available in units with brake chopper. Only one relay connector is included for FC 101/301
units. For DC link connection (Load sharing) the connector 1 can be ordered separately (Code no
130B1064)
An eight pole connector is included in accessory bag for FC 101/301 without Safe Stop.
How to Install
®
MG.33.B8.02 - VLT
is a registered Danfoss trademark
Frame size A5
IP55/Type 12
Frame sizes C1 and C2
IP55/66/Type 1/Type 12
81
