Bit 11, Relay 01:
Bit 11 = "0": Relay not activated. Bit 11 = "1": Relay 01 activated provided that Control word bit 11 is
chosen in par. 5-40 Function relay.
Bit 12, Relay 04:
Bit 12 = "0": Relay 04 is not activated. Bit 12 = "1": Relay 04 is activated provided that Control word bit
12 is chosen in par. 5-40 Function relay.
Bit 13/14, Selection of set-up:
Use bits 13 and 14 to choose from the four menu
set-ups according to the shown table: .
The function is only possible when Multi Set-Ups
is selected in par. 0-10 Active Set-Up
Bit 15 Reverse:
Bit 15 = '0': No reversing. Bit 15 = '1': Reversing. In the default setting, reversing is set to digital in par.
8-54 Reversing Select. Bit 15 causes reversing only when Ser. communication, Logic or or Logic and is
selected.
RS-485 Installation and Set-up
®
MG.33.B8.02 - VLT is a registered Danfoss trademark
Set-up Bit 14
1 0
2 0
3 1
4 1
NB!
Make a selection in par. 8-55 Set-up
select to define how Bit 13/14 gates
with the corresponding function on the
digital inputs.
Bit 13
0
1
0
1
