FC 300 Design Guide
Status Word according to PROFIdrive Profile
(STW)
The Status word is used to notify a master (e.g. a
PC) about the status of a slave.
Explanation of the Status Bits
Bit 00, Control not ready/ready
When bit 00 = "0", bit 00, 01 or 02 of the Control word is "0" (OFF 1, OFF 2 or OFF 3) - or the frequency
converter is switched off (trip).
When bit 00 = "1", the frequency converter control is ready, but there is not necessarily power supply to
the unit present (in the event of external 24 V supply of the control system).
Bit 01, VLT not ready/ready
Same significance as bit 00, however, there is a supply of the power unit. The frequency converter is
ready when it receives the necessary start signals.
Bit 02, Coasting/Enable
When bit 02 = "0", bit 00, 01 or 02 of the Control word is "0" (OFF 1, OFF 2 or OFF 3 or coasting) - or
the frequency converter is switched off (trip).
When bit 02 = "1", bit 00, 01 or 02 of the Control word is "1"; the frequency converter has not tripped.
Bit 03, No error/Trip
When bit 03 = "0", no error condition of the frequency converter exists.
When bit 03 = "1", the frequency converter has tripped and requires a reset signal before it can start.
Bit 04, ON 2/OFF 2
When bit 01 of the Control word is "0", then bit 04 = "0".
When bit 01 of the Control word is "1", then bit 04 = "1".
Bit 05, ON 3/OFF 3
When bit 02 of the Control word is "0", then bit 05 = "0".
When bit 02 of the Control word is "1", then bit 05 = "1".
146
RS-485 Installation and Set-up
Bit
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
MG.33.B8.02 - VLT ® is a registered Danfoss trademark
Bit = 0 Bit = 1
Control not Control ready
ready
Drive not ready Drive ready
Coasting Enable
No error Trip
OFF 2 ON 2
OFF 3 ON 3
Start possible Start not possible
No warning Warning
Speed ≠ refer- Speed = reference
ence
Local operation Bus control
Out of frequency Frequency limit ok
limit
No operation In operation
Drive OK Stopped, autostart
Voltage OK Voltage exceeded
Torque OK Torque exceeded
Timer OK Timer exceeded
