FC 300 Design Guide
Required Compliance Levels
Standard / environment
IEC 61000-6-3 (generic)
IEC 61000-6-4
EN 61800-3 (restricted)
EN 61800-3 (unrestricted)
EN 55011: Threshold values and measuring methods for radio interference from industrial, scientific
and medical (ISM) high-frequency equipment.
Class A1: Equipment used in a public supply network. Restricted distribution.
Class A2: Equipment used in a public supply network.
Class B1: Equipment used in areas with a public supply network (dwellings, commerce, and light
industries). Unrestricted distribution.

EMC Immunity

In order to document immunity against electrical interference from electrical phenomena, the following
immunity tests have been made on a system consisting of a frequency converter (with options, if rele-
vant), a screened control cable, and a control box with potentiometer, motor cable, and motor.
The tests were performed in accordance with the following basic standards:
• EN 61000-4-2 (IEC 61000-4-2): Electrostatic discharges (ESD)
discharges from human beings.
• EN 61000-4-3 (IEC 61000-4-3): Incoming electromagnetic field radiation, amplitude
modulated Simulation of the effects of radar and radio communication equipment as well as
mobile communications.
• EN 61000-4-4 (IEC 61000-4-4): Burst transients
by switching with a contactor, relays, or similar devices.
• EN 61000-4-5 (IEC 61000-4-5): Surge transients
lightning that strikes near installations.
• EN 61000-4-6 (IEC 61000-4-6): RF Common mode
transmitting equipment connected to connection cables.
See following EMC immunity form.
Immunity continued
FC 301/FC 302; 200-240 V, 380-500 V
Basic standard
Acceptance criterion
Line
Motor
Brake
Load sharing
Control wires
Standard bus
Relay wires
Application and Fieldbus op-
tions
LCP cable
External 24 V DC
Enclosure
AD: Air Discharge
CD: Contact Discharge
CM: Common mode
DM: Differential mode
1. Injection on cable shield.
40
Introduction to FC 300
Housing, trades, and light industries
Conducted
Class B
Class A1
Class B
Burst Surge
IEC 61000-4-4 IEC 61000-4-5
B B
2 kV/2 Ω DM
4 kV CM
4 kV/12 Ω CM
4 kV CM 4 kV/2 Ω 1)
4 kV CM
4 kV/2 Ω 1)
4 kV CM 1)
4 kV/2 Ω
2 kV CM
2 kV/2 Ω 1)
2 kV CM 2 kV/2 Ω 1)
2 kV CM 1)
2 kV/2 Ω
2 kV CM
2 kV/2 Ω 1)
2 kV CM 2 kV/2 Ω 1)
0.5 kV/2 Ω DM
2 kV CM
1 kV/12 Ω CM
— —
MG.33.B8.02 - VLT ® is a registered Danfoss trademark
Industrial environment
Radiated Conducted
Class B
Class A1
Class A1 Class A1
Class B Class A2
Simulation of interference brought about
Simulation of transients brouht e.g. by
Simulation of the effect from radio-
ESD Radiated electromagnetic field
IEC IEC 61000-4-3
61000-4-2
B A
— —
— —
— —
— —
— —
— —
— —
— —
— —
— —
8 kV AD
10 V/m
6 kV CD
Radiated
Class A1
Class A1
Class A2
Simulation of electrostatic
RF common
mode voltage
IEC 61000-4-6
A
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
10 V
RMS
—
