FC 300 Design Guide
Conversion table
Conversion index
74
2
1
0
-1
-2
-3
-4
-5
Process Words (PCD)
The block of process words is divided into two blocks of 16 bits, which always occur in the defined se-
quence.
PCD 1
Control telegram (master⇒ Control word slave)
Control telegram (slave ⇒master) Status word
RS-485 Installation and Set-up
Conversion factor
0.1
100
10
1
0.1
0.01
0.001
0.0001
0.00001
®
MG.33.B8.02 - VLT is a registered Danfoss trademark
PCD 2
Reference-value
Present outp. frequency
135
