FC 300 Design Guide
Analog output:
Number of programmable analog outputs
Terminal number
Current range at analog output
Max. load GND - analog output
Accuracy on analog output
Resolution on analog output
The analogue output is galvanically isolated from the supply voltage (PELV) and other high-voltage ter-
minals.
Control card, RS 485 serial communication:
Terminal number
Terminal number 61
The RS 485 serial communication circuit is functionally separated from other central circuits and gal-
vanically isolated from the supply voltage (PELV).
Digital output:
Programmable digital/pulse outputs
Terminal number
Voltage level at digital/frequency output
Max. output current (sink or source)
Max. load at frequency output
Max. capacitive load at frequency output
Minimum output frequency at frequency output
Maximum output frequency at frequency output
Accuracy of frequency output
Resolution of frequency outputs
1) Terminal 27 and 29 can also be programmed as input.
2) Terminal 29: Only FC 302.
The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage termi-
nals.
Control card, 24 V DC output:
Terminal number
Output voltage
Max. load
The 24 V DC supply is galvanically isolated from the supply voltage (PELV), but has the same potential
as the analog and digital inputs and outputs.
Relay outputs:
Programmable relay outputs
Relay 01 Terminal number
Max. terminal load (AC-1)
Max. terminal load (AC-15)
Max. terminal load (DC-1)
Max. terminal load (DC-13)
Relay 02 (FC 302 only) Terminal number
Max. terminal load (AC-1)
62
FC 300 Selection
1)
on 1-3 (NC), 1-2 (NO) (Resistive load)
1)
(Inductive load @ cosφ 0.4)
1)
on 1-2 (NO), 1-3 (NC) (Resistive load)
1)
(Inductive load)
1)
on 4-5 (NO) (Resistive load)
MG.33.B8.02 - VLT
®
is a registered Danfoss trademark
Max. error: 0.5 % of full scale
68 (P,TX+, RX+), 69 (N,TX-, RX-)
Common for terminals 68 and 69
Max. error: 0.1 % of full scale
FC 301: 130 mA/ FC 302: 200 mA
FC 301 ≤ 7.5 kW: 1 / FC 302 all kW: 2
1-3 (break), 1-2 (make)
240 V AC, 0.2 A
4-6 (break), 4-5 (make)
1
42
0/4 - 20 mA
500 Ω
12 bit
2
1) 2)
27, 29
0 - 24 V
40 mA
1 kΩ
10 nF
0 Hz
32 kHz
12 bit
12, 13
24 V +1, -3 V
240 V AC, 2 A
60 V DC, 1A
24 V DC, 0.1A
400 V AC, 2 A
