Danfoss VLT AutomationDrive FC 300 Design Manual page 72

FC 300 Design Guide
Product groups
VLT series
Power rating
Phases
Mains Voltage
Enclosure
Enclosure type
Enclosure class
Control supply voltage
Hardware configuration
RFI filter
Brake
Display (LCP)
Coating PCB
Mains option
Adaptation A
Adaptation B
Software release
Software language
A options
B options
C0 options, MCO
C1 options
C option software
D options
1): FC 301/ A1 enclosure only
2): Power sizes ≥ 11 kW only
Not all choices/options are available for each FC
301/FC 302 variant. To verify if the appropriate
version is available, please consult the Drive Con-
figurator on the Internet.
72
How to Order
1-3
4-6
8-10
11
12
14-15
16-17
18
19
20
21
22
23
24-27
28
29-30
31-32
33-34
35
36-37
38-39
MG.33.B8.02 - VLT ® is a registered Danfoss trademark
Description Pos
Product group 1-3
Drive series 4-6
Power rating 8-10
Phases 11
Mains voltage 11-12
Enclosure 14-15
RFI filter 16-17
Brake 18
Display 19
Coating PCB 20
Mains option 21
Adaptation 22
Adaptation 23
Software release 24-27
Software language 28
A options 29-30
B options 31-32
C0 options 33-34
C1 options 35
C option software 36-37
D options 38-39
Possible choise
FC 30x
FC 301
FC 302
0.25-75 kW
Three phases (T)
T 2: 200-240 V AC
T 4: 380-480 V AC
T 5: 380-500 V AC
T 6: 525-600 V AC
E20: IP20
E21: IP 21/NEMA Type 1
E55: IP 55/NEMA Type 12
1)
Z20: IP 20
Z21: IP 21 1)
E66: IP 66
H1: RFI filter class A1/B1
H2: No RFI filter, observes
class A2
1)
H3:RFI filter class A1/B1
HX: No filter (600 V only)
B: Brake chopper included
X: No brake chopper inclu-
ded
T: Safe Stop No brake 1)
U: Safe stop brake chop-
per 1)
G: Graphical Local Control
Panel (LCP)
N: Numerical Local Control
Panel (LCP)
X: No Local Control Panel
C: Coated PCB
X. No coated PCB
X: No mains option
1: Mains disconnect
2)
D: Load sharing
8: Mains disconnect and
load
2)
Sharing
Reserved
Reserved
Actual software
A0: MCA 101 Profibus DP
V1
A4: MCA 104 DeviceNet
A6: MCA 105 CANOpen
AX: No fieldbus
BX: No option
BK: MCB 101 General pur-
pose I/O option
BR: MCB 102 Encoder op-
tion
BU: MCB 103 Resolver op-
tion
BP: MCB 105 Relay option
BZ: MCB 108 Safety PLC
Interface
CX: No option
C4: MCO 305, Programma-
ble Motion Controller.
DX: No option
D0: DC back-up
D0: MCB 107 Ext. 24 V
back-up
