Installing the Cisco Remote PHY Shelf 7200
Installing the RPDs
2. Gently slide the RPD into the chassis. Ensure that there is no binding of the card during installation.
3. Actuate the two ejectors together to finish the connector engagement of the RPD to the chassis.
4. Secure by tightening the two Captive Screws to 6-8 Lb-in torque.
1
Captive Screw
2
Ejector
Installing the Cisco Remote PHY Shelf 7200
33
