Installing the Cisco Remote PHY Shelf 7200
Figure 2: Chassis Installation Bracket
1
After you install the chassis and secure it to the rack, remove the chassis installation brackets from the rack.
Note
The chassis does not need these brackets for supporting the weight, after all rack mount screws are secured.
Attaching the Chassis Rack-Mount Brackets
The chassis is shipped with the rack mount brackets pre-installed in the front position. The rack mount brackets
can be removed and reversed in the mid-mounting location on the chassis.
Note
After you install the chassis in the rack, the rear RF cable-management brackets can be installed on the chassis.
Attach the rack-mounting brackets either in the front or the middle of the chassis.
Attaching the Chassis Rack-Mount Brackets
Chassis Installation Bracket
Installing the Cisco Remote PHY Shelf 7200
3
