Attaching a Chassis Ground Connection

Before you begin

Warning

This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence

of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician

if you are uncertain that suitable grounding is available. Statement 1024

Before you connect the power or turn on the power to the chassis, you must provide an adequate chassis

ground (earth) connection for the chassis. A chassis ground connector is available at the rear, left side of each

Cisco Remote PHY Shelf 7200 chassis.

Installing the Cisco Remote PHY Shelf 7200

Cables from PIC0

Cables from PIC2

Cables from PIC4

Installing the Cisco Remote PHY Shelf 7200

Cables from PIC1

Cables from PIC3

Cables from PIC5
