Installing the Cisco Remote PHY Shelf 7200

Installing the Power Shelf

3. Ensure that the top and bottom Fan Module latches are engaged on every fan module to the fan tray
sheetmetal bay.
Installing the Power Shelf
The chassis ships with an AC or DC Power Shelf installed depending on the configuration. In the future you
may need to install a new Power Shelf or to swap the power system of the chassis.
Before you begin
Important
We recommend that you wire the chassis for the total 4200 W of power requirement from the facility.
Warning
If you are adding new hardware or upgrading the existing hardware, ensure that the power modules installed
in the chassis are adequate to support the hardware.
