Installing the Cisco Remote PHY Shelf 7200
Installing the Optical Cable Management Kit (Optional)
Installing the Optical Cable Management Kit (Optional)
To install the optional Optical Cable Management (OCMG) Kit, complete the following steps:
1. Remove the top two screws from the power shelf flange ears. Keep the screws safe.
1
T15 Drive Screws
2. Align the Optical Cable Management Kit to the chassis.
Installing the Cisco Remote PHY Shelf 7200
16
