Installing the Fan Tray

Before you begin

• Attach an ESD-preventive wrist strap to your wrist and connect the other end to the grounding lug

• Minimum Keep Out Areas for Proper Cooling

Installing the Cisco Remote PHY Shelf 7200

connected to the chassis.

Air flows from the front to the rear of the chassis. Air enters through the chassis RDP front panels and

power supply modules. Air is expelled from the rear of the chassis.

The keep-out areas are defined to ensure adequate space around the Cisco Remote PHY Shelf 7200

chassis. The space is necessary to ensure adequate air intake and exhaust. The figure shows the keep-out

areas for the Cisco Remote PHY Shelf 7200 chassis.
