STMicroelectronics SPC58NHADPT302S User Manual page 24

Itm Qty Ref. designator
53 1 R15
54 1 R18
55 1 R19
56 1 R20
R21, R22,R23,
R24, R25, R26,
R29, R31,R37,
R41, R49, R51,
57 24
R55, R57, R58,
R66, R67, R71,
R72, R77, R81,
R85, R88, R89
R28, R30, R45,
R50, R52, R53,
58 13 R60, R61, R65,
R69, R70, R93,
R94
59 1 R42
R43, R47, R48,
60 5
R63, R64
61 2 R44, R46
62 2 R56, R87
63 1 R68
64 1 SW1
TP1, TP2, TP27,
65 8 TP28, TP29,
TP30, TP31, TP0
TP3, TP4, TP5,
TP6, TP7, TP8,
TP9, TP10, TP12,
TP13, TP14,
TP15, TP16,
66 23
TP17, TP18,
TP19, TP20,
TP21, TP22,
TP23, TP24,
TP25, TP26
67 1 TP11
68 1 U1
69 2 U2, U3
70 1 U5
71 1 U6
72 1 U7
73 2 U9,U10
74 1 U11
UM2725 - Rev 1
Value Description
51K Resistor
249K Resistor
86K6 Resistor
43K Resistor
Resistor - not
DNM
mounted
10K Resistor
50R Resistor
4K7 Resistor
560R Resistor
1K Resistor
12K1 Resistor
Pushbutton NO
Pushbutton
B6110-0 (N3)
PCB Test point 1
TESTPOINT
pin - black
TP SMD Test point - ignore
TP-STRIP Test point - ignore
Socket Yamaichi
FPBGA302 NP351-302-772
(N5)
A6986 Volt. reg
8MHz Clock oscillator
74LVC125AMTR HCMOS buffer
74V1G08STR CMOS AND gate
HSP061-4M10Y ESD protection
Ethernet 1-port
KSZ9031RNXIA GigabitEthrnt
Ethernet PHY
Manufacturer
Vishay CRCW0603249RFKEA
Vishay CRCW060343K0FKEA
Mini-Reel CR1J10KF-MR
Neohm
Vishay CRCW0603560RFKEA
FCR0FT-1212
Delta Elettronica
Yamaichi NP351-302-774
STMicroelectronics
ECS ECS-3953M-080-BN-TR
STMicroelectronics 74LVC125AMTR
STMicroelectronics 74V1G08STR
STMicroelectronics HSP061-4M10Y
STMicroelectronics KSZ9031RNXIA
UM2725
BOM
Manufcode
B6110-0
A6986
page 24/38
