Pin
1 GPIO_46/SCK_1
2 VDD_HV_5v0
3 GPIO_71/TXD_LIN1
4 GPIO_70/RXD_LIN1
5 GPIO_45/SIN_1
6 GPIO_44/SOUT_1
7 GPIO_126/PCS_1[0]
8 GPIO_83/PCS_1[1]
9 GPIO_82/PCS_1[2]
10 VSS_HV
Connector 3 (ADC/IO): CN9
Serigraphy: AI
• Power supplies, VSS, VDD_HV_5v0
• 1xADC (8 signal)
• 8xGPIO
Pin
1 GPIO_179/AN 0
2 VDD_HV_5v0
3 GPIO_38/AN 1
4 GPIO_37/AN 2
5 GPIO_180/AN 3
6 GPIO_181/AN 4
7 GPIO_184/AN 5
8 GPIO_176/AN 6
9 GPIO_158/AN 7
10 VSS_HV
UM2725 - Rev 1
Table 13. ISU – CN8 connector pin mapping
Pin name
(Figure 8. Overview of SPC58NHADPT302S Rev. A mini module - Top
Table 14. AI - CN9 connector pin mapping
Pin name
CIS, ISU and AI connectors
Port BGA516
PC[14]
- 5.0V_SR
PE[7] E19
PE[6] E17
PC[13]
PC[12]
PH[14]
PF[3]
PF[2]
- VSS_HV
Port BGA516
PL[3] G4
- 5.0V_SR
PC[6] E2
PC[5] E1
PL[4] G5
PL[5] H5
PL[8] A1
PL[0] F5
PJ[14] M17
- VSS_HV
UM2725
D9
A9
B9
B6
B5
A4
- D4)
