eMMC interface

This paragraph describes the embedded eMMC device present on the mini module.
The figure below shows the functional diagram of the eMMC interface.
Symbol
U15 eMMC memory 8 GB
UM2725 - Rev 1
Figure 6.
Table 10.
Description
Figure 8. Overview of SPC58NHADPT302S Rev. A mini module - Top
eMMC functional diagram
eMMC interface
Position
UM2725
eMMC interface
- B1
