CIS, ISU and AI connectors

The mini module is fitted with three 5x2 box header connectors with 0.1". These connectors are polarized and
they are placed close to the edge with a space of 5 mm between each other.
The connectors have the following features:
Connector 1 (CAN/IO/SPI): CN7
Serigraphy: CIS
• Power supplies, VSS, VDD_HV_5v0
• 1xSPI with three CS
• 1xCAN
• 8xGPIO
Pin
1 GPIO_107/SCK_0
2 VDD_HV_5v0
3 GPIO_26/CAN1_TX
4 GPIO_52/ECAN1_RX
5 GPIO_108/SIN_0
6 GPIO_59/SOUT_0
7 GPIO_109/PCS_0[0]
8 GPIO_95/PCS_0[1]
9 GPIO_172/PCS_0[2]
10 VSS_HV
Connector 2 (IO/SPI/UART): CN8
Serigraphy: ISU
• Power supplies, VSS, VDD_HV_5v0
• 1xSPI with three CS
• 1xUART
• 8xGPIO
UM2725 - Rev 1
(Figure 8. Overview of SPC58NHADPT302S Rev. A mini module - Top
Table 12. CIS – CN7 connector pin mapping
Pin name
(Figure 8. Overview of SPC58NHADPT302S Rev. A mini module - Top
UM2725
CIS, ISU and AI connectors
Port BGA302
PG[11] W7
- 5.0V_SR
PB[10] Y14
PD[4] E20
PG[12] Y8
PD[11] T9
PG[13] F17
PF[15] G20
PK[12] L17
- VSS_HV
- B4).
- C4)
