5.5

Other Jumpers

Jumper Description
J29 Testmode settings
5.6 Configuration for pin shared between eMMC & SD Card Reader
The following jumpers need to configure the pin shared between eMMC & SD Card Reader set the jumpers
described in the table below.
Jumper Description
Data0 – PJ3-EVTO configuration
J26 • 1-2 D1_SD (SD-CARD)
• 2-3 D1_eMM (eMMC)
Data1 - PJ4 configuration
J30 • 1-2 D1_SD (SD-CARD)
• 2-3 D1_eMM (eMMC)
Data2 - PH5 configuration
J32 • 1-2 D2_SD (SD-CARD)
• 2-3 D2_eMM (eMMC)
Data3 - PH6 configuration
J35 • 1-2 D3_SD (SD-CARD)
• 2-3 D3_eMM (eMMC)
CLK – PJ2 configuration
J28 • 1-2 CLK_SD (SD-CARD)
• 2-3 CLK_eMM (eMMC)
FBCLK - PJ0 configuration
J33 • 1-2 FBCLK_SD (SD-CARD)
• 2-3 FBCLK_eMM (eMMC)
CMD - PJ1 configuration
J36 • 1-2 CMD_SD (SD-CARD)
• 2-3 CMD_eMM (eMMC)
UM2725 - Rev 1
Table 5.
(10 KΩ down)
Table 6. Pin shared between eMMC & SD Card Reader jumpers
Default configuration
(SD-CARD)
(SD-CARD)
(SD-CARD)
(SD-CARD)
(SD-CARD)
(SD-CARD)
(SD-CARD)
Other jumpers
Default
Close Figure 8. Overview of SPC58NHADPT302S Rev. A
1-2
Figure 8. Overview of SPC58NHADPT302S Rev. A
1-2
Figure 8. Overview of SPC58NHADPT302S Rev. A
1-2
Figure 8. Overview of SPC58NHADPT302S Rev. A
1-2
Figure 8. Overview of SPC58NHADPT302S Rev. A
1-2
Figure 8. Overview of SPC58NHADPT302S Rev. A
1-2
Figure 8. Overview of SPC58NHADPT302S Rev. A
1-2
Figure 8. Overview of SPC58NHADPT302S Rev. A
UM2725
Other Jumpers
Position
mini module - Top - B2
Position
mini module - Top - C2
mini module - Top - C1
mini module - Top - C1
mini module - Top - C1
mini module - Top - C2
mini module - Top - C1
mini module - Top - C2
page 10/38
