6.4

SD/MMC interface

This paragraph describes the Card Reader JEDED/MMC standard version 5.0 compliant.
The filter used is EMIF06-MSD02N16 by STMicroelectronics.
The SD/MMC Card Reader needs to use a power switch to limit the output current to a safe level in case the
output load exceeds the current limits threshold or a short is present.
Use an STMPS2151MTR by STMicroelectronics.
The figure below shows the SD/MMC Card Reader diagram.
The following table describes all hardware of the SD/MMC interface of the mini module and their position on PCB.
Symbol
U16
U17
U18 Connector SD reverse push-push
UM2725 - Rev 1
Figure 7.
Table 11.
Description
CMOS switch Figure 9. Overview of SPC58NHADPT302S Rev. A mini module - Bottom
Filter EMI 6-line Micro Figure 9. Overview of SPC58NHADPT302S Rev. A mini module - Bottom
Figure 8. Overview of SPC58NHADPT302S Rev. A mini module - Top
SD/MMC Card Reader diagram
SD/MMC interface
Position
UM2725
SD/MMC interface
- A2
- B2
- D1/D2
page 14/38
