5.2 JTAG/LFAST LVDS interface configuration
The following jumpers need to configure the JTAG/LFAST LVDS/SIPI:
Jumper Description
SIPI pin 3 configuration
J10 • 1-2: RDY
• 2-3: PA14
TDI_LF configuration
J11 • 1-2: TDI_LF
• 2-3: PA8
TDO_LF configuration
J12 • 1-2: TDO_LF
• 2-3: PA9
JTAG pin 13 configuration
J13 • 1-2: EVTO
• 2-3: PJ3/PQ4
PC1 / ESR0
J14 • 1-2 ESR0
• 2-3 PC1
EVTO/ESR0
J15 • 1-2 ESR0
• 2-3 EVTO
EVIO/PK10
J31 • 1-2 EVTI
• 2-3 PK10
CLKOUT/PE3
J34 • 1-2 PE3
• 2-3 CLKOUT
UM2725 - Rev 1
Table 2. JTAG/LFAST/SIPI configuration jumpers
Default
1-2
(RDY)
1-2
(TDI_LF)
1-2
(TDO_LF)
1-2
(EVTO)
1-2
(ESR0)
1-2
(ESR0)
1-2
(EVTI)
1-2
(ESR0)
JTAG/LFAST LVDS interface configuration
Position
Figure 8. Overview of SPC58NHADPT302S Rev. A
mini module - Top
Figure 8. Overview of SPC58NHADPT302S Rev. A
mini module - Top
Figure 8. Overview of SPC58NHADPT302S Rev. A
mini module - Top
Figure 8. Overview of SPC58NHADPT302S Rev. A
mini module - Top
Figure 8. Overview of SPC58NHADPT302S Rev. A
mini module - Top
Figure 8. Overview of SPC58NHADPT302S Rev. A
mini module - Top
Figure 8. Overview of SPC58NHADPT302S Rev. A
mini module - Top
Figure 8. Overview of SPC58NHADPT302S Rev. A
mini module - Top
UM2725
- B3
- A3
- A3
- B3
- B3
- B3
- C3
- B3
