ConFigurATion menu
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) Cons uv o i Fails
2) Cons ir o i Fails
3) Time delay
CAliBrATion menu
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) loop test
2) d/A trim
3) Calibrate o i
3.2
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
Allowable number of consecutive UV o i failures to produce a fault. Factory set
to three (minutes). This is the time between fault occurrence and annunciation.
Allowable number of consecutive IR o i failures to produce a fault. Factory set
to three (minutes). This is the time between fault occurrence and annunciation.
Time Delay before alarm is indicated (0 to 15 seconds). Factory default is
zero seconds.
important: In addition to lengthening the time period between the outbreak
of a fire and the fire alarm, a time delay can also affect sensitivity. Consult the
factory for guidance before setting a time delay over five seconds.
note: FM Approval covers the detector's performance with zero time delay only.
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
This test allows the operator to manually set the analog signal output at 1, 2,
3, or between 4 and 20 mA in increments of 2 (4, 6, 8, etc.). When the loop test
is completed, ensure that the current loop is returned to automatic operation.
This function allows adjustment of the 0–20 mA span factor.
Trim in increments of 0.1 mA resolution only.
This procedure calibrates the o i test signal for the UV and IR sensors.
1. Bypass/disable all Alarm outputs connected to the detector.
2.
Thoroughly clean the sensor and o i reflector for the UV and IR
sensors. Check each of the three o i source openings for
contaminants and clean as needed.
3.
Cover the detector with the provided cover.
4.
Initiate o i Calibration. The detector performs the calibration
automatically and notifies the operator upon completion. The
procedure takes approximately two minutes.
5.
Upon completion of o i calibration, remove the cover and return all
alarm outputs to service.
Configuration Menu
1) Consecutive UV Oi Fails
2) Consecutive IR Oi Fails
3) Time Delay
Calibration Menu
1) Loop test
2) D/A trim
3) Calibrate Oi
NOTe
16
95-8636
