sTATus inFo menu

This menu (read-only) shows extensive status information about the detector.
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) warm up (Y/n)
2) Fire (Y/n)
3) uv Alarm (Y/n)
4) ir Alarm (Y/n)
5) TdsA Alarm (Y/n)
6) Quick Alarm (Y/n)
7) uv Pre Alarm (Y/n)
8) ir Pre Alarm (Y/n)
9) Auto uv o i Flt (Y/n)
10) Auto ir o i Flt (Y/n)
11) manual o i at start (Y/n) Manual o i at start. On power-up a manual o i was started. Check the external
12) snsr hdwr Flt (Y/n)
13) hiB hdwr Flt (Y/n)
14) int Comm Flt
15) incompatible Flt
16) voltage Fault (Y/n)
17) hardware menu
18) o i menu
3.2
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
Device is in the power-up time delay (warm-up) mode.
Indicates "Y" if the device is in a fire alarm status — analog output is at 20 mA,
fire alarm relay is actuated, and LED is red.
Indicates "Y" if the UV detector is signaling an alarm.
Indicates "Y" if the IR detector is signaling an alarm.
Indicates "Y" if the IR detector is signaling a TDSA alarm.
Indicates "Y" if the IR detector is signaling a quick alarm.
Indicates "Y" if the UV detector is in a pre-alarm state.
Indicates "Y" if the IR detector is in a pre-alarm state.
Automatic UV o i Fault. Check viewing window and o i reflector plate for cleanliness.
Automatic IR o i Fault. Check viewing window and o i reflector plate for cleanliness.
input wiring.
Sensor hardware fault.
HART Interface Board hardware fault.
Internal communication fault.
Sensor module firmware version is not compatible with HART Interface
Board.
Detector operating voltage is out of tolerance.
Refer to sub-menu.
Refer to sub-menu.
Status Info Menu
1) Warm Up (Y/N)
2) Fire (Y/N)
3) UV Alarm (Y/N)
4) IR Alarm (Y/N)
5) TDSA Alarm (Y/N)
6) Quick Alarm (Y/N)
7) UV Pre Alarm (Y/N)
8) IR Pre Alarm (Y/N)
9) Auto UV Oi Fault (Y/N)
10) Auto IR Oi Fault (Y/N)
11) Manual Oi at Start
12) Sensor Hdwr. Fault (Y/N)
13) HIB Hardware Fault (Y/N)
14) Internal Com. Fault (Y/N)
15) Incompatible Fault (Y/N)
16) Voltage Fault (Y/N)
17) Hardware Menu
18) Oi Menu
