X5200 rooT menu

When HART communication is established, the first menu displayed is the X5200 Root menu:
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)

3) Device Info Menu

4) Command Menu
5) Device Setup Menu
1) Fire (Yes/no)
2) Fault (Yes/no)
3) device info menu
4) Command menu
5) device setup menu This menu allows various setup, configuration, and calibration functions.
deviCe inFo menu
This menu allows access to a variety of "read-only" information.
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) general info menu Factory information.
2) hArT info menu
3) status info menu
4) detector settings
5) history menu
3.2
Indicates "Y" if the device is in a fire alarm status — analog output is at 20 mA,
fire alarm relay is actuated, and LED is red.
Indicates "Y" if a fault condition exists. Go to "Device Info" and select "Status
Info" to determine the nature of the fault.
Provides access to manufacturer and HART information, current device status,
factory settings, and history logs.
This menu allows the operator to initiate a manual o i test and to perform
various reset/ clear functions.
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
HART Specific Variables.
Current operating status and/or diagnostic information.
Factory settings relating to relay operation, detector sensitivity, and response.
Display log files: Alarm, Fault, General.
5 95-8636
