hArT seTuP

This menu allows editing of the following functions:
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) Poll addr
2) Final asmbly num
3) Tag
4) long tag
5) date
6) descriptor
7) message

reAl Time CloCk

To set the real time clock, enter the current time and date information into the appropriate fields.
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) rTC seconds
2) rTC minutes
3) rTC hours
4) rTC date
5) rTC month
6) rTC Year
3.2
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
Address used by the host device to identify a field device. Note that if it
is set to an address other than "0," the Detector will output 1 mA.
A number that is used for identification purposes and is associated with the
overall field device.
Text that is associated with the field device installation. This text can be used
by the operator in any way. Max of eight character input.
Text that is associated with the field device installation. This text can be used
by the operator in any way. Max of 32 character input.
Any date chosen by the operator to be used for any purpose. XX/XX/XXXX
(month/day/year).
Text associated with the field device that can be used by the operator in any
way.
Text associated with the field device that can be used by the operator in any
way.
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Real Time Clock
0 to 59
0 to 59
0 to 23
1 to 31
1 to 12
0 to 99
HART Setup
1) Poll addr
2) Final asmbly num
3) Tag
4) Long tag
5) Date
6) Descriptor
7) Message
Real Time Clock
1) RTC Seconds
2) RTC Minutes
3) RTC Hours
4) RTC Date
5) RTC Month
6) RTC Year
18
