deTeCTor seTTings

This menu shows factory settings relating to relay operation, detector sensitivity, and response.
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) uv mode
2) ir mode
3) ArC rejection
4) uv sensitivity
5) ir sensitivity
6) Auto o i enabled
7) Fire relay (nl/l)
8) Fault relay (nl/l)
9) Aux relay (nl/l)
10) heater disabled
11) Aux Function
12) Aux ir Function
13) Aux relay (ne/nde)

hisTorY menu

This menu provides historical information about the detector. Up to 32 events in each of the three
categories will be kept in non-volatile memory. When the log is full, the oldest event will be overwritten.
The most recent event will be displayed first.
X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) Alarm log
2) Fault log
3) general log
3.2
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
UV Mode: Standard or Arc.
IR Mode: TDSA and Quick or TDSA only.
Detector ARC Rejection setting: Low, Medium, High, or Very High.
Detector UV sensitivity setting; Low, Medium, High, or Very High.
Detector IR sensitivity setting; Low, Medium, High, or Very High.
Auto o i enabled. If (Y) an o i test will be conducted periodically without
manual input.
Fire Relay: Latching (L) or Non-Latching (NL).
Fault Relay: Latching (L) or Non-Latching (NL).
Aux Relay: Latching (L) or Non-Latching (NL).
Heater disabled. If (Y) the optics heater is not enabled to prevent
condensation and icing.
Aux function: Pre Alarm, IR Alarm, UV Alarm, UV or IR Alarm, UV and IR alarm
Aux IR function: TDSA and Quick or TDSA only.
Aux Relay: Normally Energized (NE) or Normally De-Energized (NDE)
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
Scroll through 32 Alarm Logs with time, date, and temperature stamp.
Scroll through 32 Fault Logs with time, date, and temperature stamp.
Scroll through 32 General Logs with time, date, and temperature stamp.
Detector Settings
1) UV Mode
2) IR Mode
3) ARC Rejection
4) UV Sensitivity
5) IR Sensitivity
6) Auto Oi Enabled
7) Fire Relay (NL/L)
8) Fault Relay (NL/L)
9) Aux Relay (NL/L)
10) Heater Disabled
11) Aux Function
12) Aux IR Function
13) Aux Relay (NE/NDE)
13
History Menu
1) Alarm Log
2) Fault Log
3) General Log
