Condensed sTATus

X5200 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
1) Xmtr Addstatus 0
2) Xmtr Addstatus 1
3) Xmtr Addstatus 2
4) Xmtr Addstatus 3
5) operating mode
3.2
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
Fire Alarm
UV Alarm
IR Alarm
TDSA Alarm
Quick Alarm
o i Cal Alarm
Manual o i Active
Warm-up
UV Pre Alarm
IR Pre Alarm
Fault
Manual UV o i Fault
Manual IR o i Fault
Auto UV o i Fault
Auto IR o i Fault
UV o i Cal Fault
IR o i Cal Fault
Temperature Out of Range
Voltage Out of Range Fault
Manual o i at Start
Hardware Fault
HART Fault
Modbus Communication Fault
Incompatible Version
Fault
Fire Alarm
HART Info Menu
1) Universal rev
2) Field dev rev
3) Final asmbly num
4) Tag
5) Long tag
6) Date
7) Descriptor
8) Message
9) Num req preams
10) HART PV Menu
11) Condensed Status
9
Condensed Status
1) Xmtr Addstatus 0
2) Xmtr Addstatus 1
3) Xmtr Addstatus 2
4) Xmtr Addstatus 3
5) Operating Mode
