A.5.8 Wireless LAN interface (radio 2)
WLAN standards
Frequency bands 5 GHz indoor
(EU), indoor and outdoor (USA)
Frequency bands 5 GHz indoor
and outdoor (EU/USA)
Frequency bands 5 GHz indoor
and outdoor (USA)
WLAN modes
Modulation Techniques
Automatic Rate Selection (ARS) Available.
Transmission rate
Data rates
Short guard interval (802.11n)
Output power limitation
Output power @ 5 GHz
Bandwidth (802.11ac)
Antenna
A.5.9 Configuration interface
LOCAL TERMINAL
CONNECTOR
RS1800 series
IEEE 802.11ac/an; MU-MIMO 2x2; 20/40/80 MHz; 5 GHz
5170-5330 MHz; max. 200 mW EIRP allowed
5490-5710 MHz; max. 1000 mW EIRP allowed
5735-5835 MHz; max. 1000 mW EIRP allowed
5 GHz Operation: 802.11a only; 802.11a/n; 802.11n.
OFDM: BPSK, QPSK, DBPSK, DQPSK,16-QAM, 64-QAM, 256-QAM.
Automatic.
802.11a,h (5 GHz): 54, 48, 36, 24, 18, 12, 9 and 6 Mbps (OFDM modulation)
802.11n, 20 MHz channel bandwidth: MCS0-15 allow up to 150 Mbps PHY rate at
20 MHz channel bandwidth, 2 streams, short guard interval
802.11n, 40 MHz channel bandwidth: MCS0-15 allow up to 300 Mbps PHY rate at
40 MHz channel bandwidth, 2 streams, short guard interval
802.11ac, 20 MHz channel bandwidth: Allow up to 173 Mbps PHY rate with two
streams or up to 87 Mbps PHY with one stream
802.11ac, 40 MHz channel bandwidth: Allow up to 400 Mbps PHY rate with two
streams or up to 200 Mbps PHY with one stream
802.11ac, 80 MHz channel bandwidth: Allow up to 867 Mbps PHY rate with two
streams or up to 433 Mbps PHY with one stream
On/off switchable; increase of throughput by reduction of the guard intervals from
800ns to 400ns
Adjustable
Max. 18,12 dBm (200mW EIRP)
20/40/80 MHz
Integrated directional dual-band MIMO array with 4.88 dB peak gain @ 5 GHz
RS-232 9600-8-N-1 without flow control.
RJ45 female on the rear panel.
